Accela Pump Dynamic Mixer Installation Guide
Adding the dynamic mixer to the Accela™ Pump ensures mixing of complex or relatively incompatible solvents and
reduces the chromatographic baseline noise for applications using proportioned mobile phases. The mixer also
increases the accuracy and reproducibility of complex ternary and quaternary gradients. The mixer adds 35 μl of
gradient delay volume to the system.
Accela Pump
Dynamic
Mixer
Option Kit
Required
To install the dynamic mixer, you must have these tools:
Tools
Instructions
Step 1: Removing the Chassis from the Housing
for Installing
Step 2: Removing the Drip Tray
the Mixer
Step 3: Removing the Front Panel
Step 4: Installing the Mixer
Step 5: Reassembling the Pump
Step 6: Reconnecting the Pump to the LC System
Revision A 60157-97001
Copyright© 2008 Thermo Fisher Scientific Inc.
All rights reserved.
CAUTION The dynamic mixer must be installed by a Thermo Fisher Scientific field service
engineer.
Contents
•
Accela Pump Dynamic Mixer Option Kit
•
Required Tools
•
Instructions for Installing the Mixer
Kit contents
Dynamic mixer
Bracket
Digital cable
Socket head cap screw, M3×10, stainless steel
In-line filter holder with cartridge, stainless steel
Tubing, stainless steel, 0.005-in. ID×0.0625-in. OD, 20-cm length
Tubing, stainless steel, 0.005-in. ID×0.0625-in. OD, 10-cm length
Tubing, stainless steel, 0.005-in. ID×0.0625-in. OD, 5-cm length
Fitting, swage front ferrule for 1/16-in. tubing, stainless steel
Fitting, swage back ferrule for 1/16-in. tubing, stainless steel
Compression nut, 1/16 in., 10-32, stainless steel
• #2 Phillips screwdriver
• 8-mm and 1/4-in.×5/16-in. open-end wrenches
• Needle nose pliers
• 2.5-mm ball driver (supplied in the Accela Pump accessory kit)
T
CAUTION
o prevent instrument damage, use ESD protection when handling electronic boards
and components.
Quantity
Part Number
1
00109-99-00037
1
60157-10011
1
60157-63018
2
00619-01-00028
1
00109-99-00019
1
00301-01-00009
1
00301-01-00008
1
00301-01-00017
6
00101-08-00001
6
00101-08-00002
6
2522-1880
