Keysight Technologies N7015A Quick Start Manual

Type-c high speed test fixture kit

Hide thumbs Also See for N7015A:

Download this manual

N7015A Type-C High Speed Test Fixture Kit

N7015A Kit

Standard

Contents

Optional Accessories Included in the N7015A Kit if Ordered with the Kit

Type-C Low Speed Signal Access and Control Fixture

Low Speed Fixture

(N7016A)

Quick Start and Accessories Guide

Wrench

(8710-2803)

Type-C High

Speed Test Fixture

N7015A - 016 Option:

Power Supply Plug

USB Cable

(8121-1242)

Connector

(0360-2693)

Other Keysight Type-C Product(s) for use with N7015A

(sold separately)

N7018A Type-C

Test Controller

Replacement Fuses

(Qty. 4)

(2110-0623)

N7015A - 017 Option:

Type-C Receptacle Adapter

N7017A Adapter

Page 1 N7018A Type-C Type-C High Test Controller Speed Test Fixture Optional Accessories Included in the N7015A Kit if Ordered with the Kit N7015A - 016 Option: N7015A - 017 Option: Type-C Low Speed Signal Access and Control Fixture Type-C Receptacle Adapter...
Page 2 N7018A Type-C Test Controller It is recommended that you use the N7015A with the N7018A Type-C Test Controller as the N7018A is a superset of most of the features of the N7016A and additionally provides power delivery controller capabilities and integrated testing over Type-C interfaces through a single connection.
