N7015A Type-C High Speed Test Fixture Kit

N7015A Kit

Standard

Contents

If you are using N7015A with N7018A

Download the Keysight N7018A Type-C Test Controller software from

the host computer to be used for the connection setup.

Detailed information on how to use N7015A and N7018A is available in the Keysight USB Type-C Connectivity Solution

User's Guide. You can download this guide from www.keysight.com/find/N7015A.

Quick Start and Accessories Guide

Wrench

(8710-2803)

Type-C High

Speed Test Fixture

Other Keysight Type-C Product(s) for use with N7015A

(sold separately)

N7018A Type-C

Test Controller

www.keysight.com/find/N7018A

and install it on

Need help?

Do you have a question about the N7015A and is the answer not in the manual?

Page 1 Detailed information on how to use N7015A and N7018A is available in the Keysight USB Type-C Connectivity Solution User’s Guide. You can download this guide from www.keysight.com/find/N7015A.
Page 2 Keep the red dot on the cable facing up to ensure proper signal identification. CAUTION: Minimize twisting the N7015A cables while connecting these to the oscilloscope or the N7018A test fixture. © Keysight Technologies 2020 N7015-92003, January 2020 For more information: Visit http://www.keysight.com/find/N7015A...
