- Page 1 CEILING FAN OWNER'S MANUAL READ AND SAVE THESE INSTRUCTIONS MODELS: 52-625-5AS-242 52-625-5CN-13 FAN RATING AC 120V. 60Hz CUL LISTED MODEL: AC-552OD...
-
Page 2: Tools And Materials Required
1. TOOLS AND MATERIALS REQUIRED Philips screw driver Blade screw driver 11 mm wrench Step ladder Wire cutters 2. PACKAGE CONTENTS Unpack your fan and check the contents. You should have the following items: a. Blade set (5) b. Hanger bracket assembly c. -
Page 3: Safety Rules
3. SAFETY RULES 1. To reduce the risk of electric shock, insure Wait for fan to stop before changing the electricity has been turned off at the circuit setting of the slide switch. breaker or fuse box before beginning. Avoid placing objects in the path of the 2. -
Page 4: Mounting Options
4. MOUNTING OPTIONS If there isn't an existing cUL listed mounting box, then read following instructions. Disconnect the power by removing fuses or turning off circuit breakers. Secure the outlet box directly to the building Outlet box structure. Use appropriate fasteners and building materials. -
Page 5: Hanging The Fan
5. HANGING THE FAN Hanger bracket REMEMBER to turn off the power. Follow the steps below to hang your fan properly: Ceiling canopy Step 1. Remove the decorative canopy bottom cover from the canopy by turning the cover counter clockwise. (Fig. 5) Canopy cover Figure 5... -
Page 6: Installation Of Safety Support
6. INSTALLATION OF SAFETY SUPPORT An additional safety support is provided to Hanger bracket Safety cable prevent the fan from falling. Secure the safety cable to the ceiling joist with screw and washer, as illustrated in Figure 9. Figure 9 7. - Page 7 Step 2. (Figure 12) Motor to Receiver Electrical Connections: Connect the black wire from the Outlet box fan to black wire marked "TO MOTOR L". Connect the white wire from the fan to the White (neutral) Black (hot) white wire marked "TO MOTOR N" from the Green or bare copper (ground) Black ("AC IN L")
-
Page 8: Finishing The Installation
8. FINISHING THE INSTALLATION Outlet box Step 1. Tuck connections neatly into ceiling outlet box. Hanger bracket Step 2. Slide the canopy up to hanger bracket and place the key hole on the canopy Screws over the screw on the hanger bracket, turn canopy until it locks in place at the narrow section of the key holes. -
Page 9: Installing The Light Kit
10. INSTALLING THE LIGHT KIT NOTE: Before starting installation, disconnect the power by turning off the circuit breaker or removing the fuse at fuse box. Turning power off using the fan switch is not suffi- cient to prevent electric shock. Step 1. -
Page 10: Installing The Battery
12. INSTALLING THE BATTERY Insert the 3 volt battery (included) and make sure they are seated correctly in each recess with the Positive + sign facing up. (Fig. 17) 13. OPERATING Figure 17 INSTRUCTIONS Restore power to ceiling fan and test for proper operation. -
Page 11: Care Of Your Fan
The Reverse switch is located on the motor housing. Slide the switch to the Left for warm weather operation. Slide the switch to the Right for cool weather operation. Speed settings for warm or cool weather depend on factors such as the room size. Ceiling height, number of fans and so on. -
Page 12: Troubleshooting
15. TROUBLESHOOTING Problem Solution Fan will not start. 1. Check circuit fuses or breakers. 2. Check line wire connections to the fan and switch wire connections in the switch housing. CAUTION: Make sure main power is off. 3. Check to make sure the dip switches from the transmitter and receiver are set to the same frequency.
