CEILING FAN

OWNER'S MANUAL
READ AND SAVE THESE INSTRUCTIONS
MODEL: 52-120-5CN-SN
52-120-5WA-13
FAN RATING AC 120V. 60Hz
UL LISTED MODEL : AC-552

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 52-120-5CN-SN and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Savoy House 52-120-5CN-SN

Summary of Contents for Savoy House 52-120-5CN-SN

  • Page 1: Ceiling Fan

    CEILING FAN OWNER'S MANUAL READ AND SAVE THESE INSTRUCTIONS MODEL: 52-120-5CN-SN 52-120-5WA-13 FAN RATING AC 120V. 60Hz UL LISTED MODEL : AC-552...

  • Page 2: Tools And Materials Required

    1. TOOLS AND MATERIALS REQUIRED Philips screw driver Blade screw driver 11 mm wrench Step ladder Wire cutters 2. PACKAGE CONTENTS Unpack your fan and check the contents. You should have the following items; a. Set of blades assembly (5) b.

  • Page 3: Safety Rules

    3. SAFETY RULES 1. To reduce the risk of electric shock, insure Avoid placing objects in the path of the electricity has been turned off at the circuit blades. breaker or fuse box before beginning. 9. To avoid personal injury or damage to the 2.

  • Page 4: Mounting Options

    4. MOUNTING OPTIONS If there isn't an existing UL listed mounting box, then read the following instructions. Disconnect the power by removing fuses or turning off circuit breakers. Secure the outlet box directly to the Outlet box building structure. Use appropriate fasteners and building materials.

  • Page 5: Hanging The Fan

    5. Hanging the Fan Hanger bracket REMEMBER to turn off the power. Follow the steps below to hang your fan properly: Ceiling Step 1. Remove the decorative canopy canopy bottom cover from the canopy by turning the cover counter clockwise. (Fig. 5) Canopy Step 2.

  • Page 6: Make The Electric Connections

    6. MAKE THE ELECTRIC CONNECTIONS Code switch WARNING: To avoid possible electrical shock, be sure electricity is turned off at the main fuse box before wiring. NOTE: This remote control unit is equipped with 16 code combinations to prevent possible interference from or to Figure 9 other remote units.

  • Page 7: Finishing The Installation

    Note: Fan must be installed at a maximum distance of 30 feet from the transmitting unit for proper signal transmission between the transmitting unit and the fan's receiving unit. 7. FINISHING THE Outlet box INSTALLATION Hanger Step 1. Tuck connections neatly into bracket ceiling outlet box.

  • Page 8: Attaching The Fan Blades

    8. ATTACHING THE FAN BLADES Step 1 Attach the blade to the blade bracket using the screws and fiber washers as shown in Figure 13. Start screw into bracket. Repeat for the two remaining screws. Screws Step 2 Tighten each screw. Make sure the blade is straight.

  • Page 9: Installing The Led Light Kit

    10. INSTALLING THE LED LIGHT KIT NOTE: Before starting installation, discon- nect the power by turning off the circuit breaker or removing the fuse at fuse box. Turning power off using the fan switch is not sufficient to prevent electric shock. Step 1.
  • Page 10 12. OPERATING INSTRUC- TIONS Restore power to ceiling fan and test for proper operation. A. HI, MED, and LOW buttons: These three buttons are used to set the fan speed as follows: HI= high speed Med= medium speed Low= low speed B.

  • Page 11: Installing The Battery

    13. INSTALLING THE BATTERY Install 9 volt battery (included), to prevent damage to transmitter, remove the battery if not used for long periods. (Fig. 201) Figure 20 14. TROUBLESHOOTING Problem Solution Fan will not start. 1. Check circuit fuses or breakers. 2.
