Related Manuals for AND UB-525
Summary of Contents for AND UB-525
- Page 1 Wrist Digital Blood Pressure Monitor Instruction Manual Original Manuel d’instructions Traduction Manual de Instrucciones Traducción Manuale di Istruzioni Traduzione 使用手冊 翻譯 1WMPD4003120E...
-
Page 2: Table Of Contents
WHO Classification Indicator ..........................13 About Blood Pressure ............................13 What is Blood Pressure? ..........................13 What is Hypertension and How is it Controlled? ..................13 Why Measure Blood Pressure at Home? ..................... 14 WHO Blood Pressure Classification ......................14 Blood Pressure Variations .......................... -
Page 3: Dear Customers
Precision components are used in the construction of this device. Extremes in temperature, humidity, direct sunlight, shock or dust should be avoided. Clean the device with a dry, soft cloth or a cloth dampened with water and a neutral detergent. Never use alcohol, benzene, thinner or other harsh chemicals to clean the device. - Page 4 If you have had a mastectomy, please consult a doctor before using the device. Do not let children use the device by themselves and do not use the device in a place within the reach of infants. It may cause accidents or damage.
-
Page 5: Parts Identification
Parts Identification button ( average, memory and change of preset parameters) Display button START Battery cover Cuff Alkaline batteries (LR03 or AAA) Display MEMORY Systolic pressure Average Diastolic pressure WHO classification indicator Pressure bar indicator IHB/AFib symbol Heart mark Pulse rate... -
Page 6: Symbols
Diastolic blood pressure in mmHg Pulse per minute Battery installation guide Direct current Serial number Date of manufacture Type BF: Device and cuff are designed to provide special protection against electrical shocks. EC directive medical device label International protection symbol WEEE label Manufacturer EU-representative... - Page 7 Take another measurement. Unstable blood pressure due to movement during measurement Remain still during measurement. The systolic and diastolic values are within 10 mmHg of each other. The pressure value did not increase during inflation. Apply the cuff correctly, and take The cuff is not applied correctly.
-
Page 8: Using The Monitor
Use the specified batteries only. The batteries provided with the device are for testing monitor performance and may have a limited life. Remove the batteries if the device is not to be used for a long period of time. The batteries may leak and cause a malfunction. -
Page 9: Applying The Cuff
For the most accurate blood pressure measurement: Remain still and keep quiet during measurement. Sit down in a comfortable position. Place your elbow on a table with your palm facing upward and the cuff is at the same level as your heart. -
Page 10: Measurement
Notes: The device is provided with an automatic power shut-off function which stores the current data in the memory and turns the device off automatically one minute after measurement. Allow at least three minutes between measurements on the same person. -
Page 11: Measurements
Measurements Note: The UB-525, once used, will provide an inflation appropriate to the user. 1. Wrap the cuff around your wrist. Sit comfortably with the cuff at the same level as your heart and relax. 2. Press the button. All of the display segments are displayed. -
Page 12: Recalling The Memory Data
Average of all the data device off. Number of all data 2. Use the following buttons to display data (of number and measurement data). button The device displays the average of all measurements and the number of data are displayed. -
Page 13: What Is The Ihb/Afib Indicator
(AFib) occurs when the electrical signal in the atrium becomes confused and leads to disturbances in the pulse interval. AFib can cause blood to stagnate in the heart, which can easily create clots of blood, a cause of stroke and... -
Page 14: Who Classification Indicator
What is Hypertension and How is it Controlled? Hypertension, an abnormally high arterial blood pressure, if left unattended can cause many health problems including stroke and heart attack. Hypertension can be controlled by altering lifestyle, avoiding stress, and with medication under a doctor’s supervision. -
Page 15: Why Measure Blood Pressure At Home
Why Measure Blood Pressure at Home? Blood pressure measured at a clinic or doctor's office may cause apprehension and can produce an elevated reading, 25 to 30 mmHg higher than that measured at home. Home measurement reduces the effects of outside influences on blood pressure readings, supplements the doctor's readings and provides a more accurate, complete blood pressure history. -
Page 16: Troubleshooting
Place your arm on a table with your palm facing The cuff position is not correct. Readings are too high upward and the cuff at the same level as your or too low. heart. If you have a very weak or irregular heartbeat, the device may have difficulty in determining your blood pressure. -
Page 17: Maintenance
Maintenance Do not open the device. It uses delicate electrical components and an intricate air unit that could be damaged. If you cannot fix the problem using the troubleshooting instructions, contact the authorized dealer in your area or our customer service department. The A&D customer service will provide technical information, spare parts and units to authorized dealers. - Page 18 IP classification is the degrees of protection provided by enclosures in accordance with IEC 60529. This device is protected against solid foreign objects of 12 mm diameter and greater such as a finger. This device is not protected against water.
- Page 19 MEMO English 18...
- Page 20 A&D Company, Limited 1-243 Asahi , Kitamoto-shi, Saitama 364-8585, JAPAN Telephone: [81] (48) 593-1111 Fax: [81] (48) 593-1119 Emergo Europe B.V. Prinsessegracht 20, 2514 AP The Hague, The Netherlands Telephone: [31] (70) 345-8570 Fax: [31] (70) 346-7299 A&D INSTRUMENTS LIMITED Unit 24/26 Blacklands Way, Abingdon Business Park, Abingdon, Oxfordshire OX14 1DY United Kingdom Telephone: [44] (1235) 550420...
