INIM Electronics Air2 Series Installation And Programming Manual
Dual pir wireless detector for outdoor use
Hide thumbs
Also See for Air2 Series:
- Installation and programming manual (16 pages) ,
- Installation and programming manual (16 pages) ,
- Installation and programming manual (24 pages)
Related Manuals for INIM Electronics Air2 Series
Summary of Contents for INIM Electronics Air2 Series
- Page 1 Installation and programming manual Air2-ODI100W Dual PIR wireless detector for outdoor use Installation and programming manual...
-
Page 2: Table Of Contents
Order codes ........11 Copyright The information contained in this document is the sole property of INIM Electronics s.r.l. No part may be copied without written authorization from INIM Electronics s.r.l. All rights reserved. -
Page 3: General Information
Web: www.inim.biz The persons authorized by the manufacturer to repair or replace the parts of this system, hold authorization to work on INIM Electronics brand devices only. Description of the product • Wireless detector for outdoor use •... - Page 4 Air2-OTT100W Table 2: Mechanical parts description “U” shaped bracket “L” shaped bracket Hermetic casing base Electronic holder (sensors in front and transceiver on the back) Cover with Fresnel lens Lower PIR range adjustment knob Anti tamper microswitch Electronics and sensors “O-ring”...
-
Page 5: Package Contents
Installation and programming manual The Air2-ODI100W detector communicates with INIM intrusion control panel via the Air2 two-way wireless intrusion protection system. Table 4: Technical specifications of Air2 system range 868.0 - 868.6MHz Operating frequency selectable channels 868.1, 868.3, 868.5MHz Communication type Two-way Modulation GFSK... -
Page 6: Operating Principles
Air2-OTT100W Table 6: Side view PIR2 Distance position 10 m 1.2m 12 m These distances are reached when the detector is installed at about 120cm (height). Operating principles The detector operates in the AND mode of PIRs generating an alarm when both sensors detect a presence. -
Page 7: Test" Function
Installation and programming manual “Test” function This function has been implemeted in order to make the detector easy to set up. The function can be activated disconnecting and connecting again the jumper (table 3, R); within a minute the function will be operative. In this mode the LED will be lighted for each detection. -
Page 8: Mounting
Air2-OTT100W Mounting Unscrew the screw for the cover enclosure (table 2, J). Remove the cover with lens (table 2, E). Unscrew the fixing screws (table 2, M) of the detector to the waterproof rear casing. Fix the hermetic casing (table 2, C) on the wall, or on a pole (be sure the pole is stable and ripple free). -
Page 9: Programming
Installation and programming manual PROGRAMMING In order to make the detector suitable for outdoor applications, a single sensor adjustment system has been implemented. In the tables below are shown the DIP switch configurations (table 3, U): Table 8: Infrared sensitivity adjustment PIR 1 sensitivity PIR 1 sensitivity DIP 1... -
Page 10: Appendix 1 Declaration Of Conformity
1999/5/EC. Islenska: Hér með lýsir INIM Electronics yfi r því að Air2-ODI100W er í samræmi við grunnkröfur og aðrar kröfur, sem gerðar eru í tilskipun 1999/5/EC. -
Page 11: Appendix 2 Order Codes
Installation and programming manual Appendix 2 ORDER CODES Please quote the following order codes when ordering items from the INIM Electronics product range: Code Product description Air2-Aria Tastiera via radio con display grafico retroilluminato Air2-BS200/10 Wireless transceiver module, 10 terminals Air2-BS200/30 Wireless transceiver module, 30 terminals Air2-BS200/50... - Page 12 Air2-ODI100W ISO 9001 Quality Management certified by BSI with certificate number FM530352 via Fosso Antico snc - fraz. Centobuchi 63076 Monteprandone (AP) ITALY Tel. +39 0735 705007 _ Fax +39 0735 704912 info@inim.biz _ www.inim.biz...
