INIM Electronics Iris ID200 Quick Start Manual

991c/01
991e/01
991a/01
For information regarding device placement, coverage and method of installation, refer
to the established standard regulations and codes relating to automatic fire-detection
systems. Iris series detectors are compliant with EN54-7: Smoke detectors – Point
detectors using the scattered light principle, light transmission or ionization (ID100 and
ID300 models only) and EN54-5: Heat detectors – point detectors (for ID200 and ID300
models only).
Iris series detectors offer wide-spectrum detection of smoke particles generated by the majority of fires. They
are suitable for most applications and provide first-rate early warning.
The EITK-DRV driver, supplied by INIM Electronics, allows you to change the operating parameters to suit specific
environment conditions. This device permits easy programming and verification of contamination and
performance. For further details, refer to "Using the EITK-DRV driver" section.
During standby status, these detectors have low current draw, 80PA. However, in the event of alarm the current
draw increases to a maximum of 40mA thus signalling the condition to the control panel.
INIM Electronics offers three Iris series conventional fire-detectors, which can be identified by the technical
specifications/serial number on the back of the detector.
Optical detector equipped with a reference chamber based on the
scattered light principle (Tyndall effect). This detector must be installed in
draught and obstacle free place which guarantees appropriate air-flow
into the reference chamber.
The detector will trigger an alarm when the level of smoke inside the
reference chamber reaches the following values:
• 0.08 dB/m (mode set via the EITK-DRV)
• 0.10 dB/m (mode set via the EITK-DRV)
• 0.12 dB/m (pre-set mode)
• 0.15 dB/m (mode set via the EITK-DRV)
Heat detector with heat-sensitive element capable of sensing the
temperature within the protected environment.
The operating modes, programmable via the EITK-DRV are:
• "A1R" (pre-set); the detector signals alarm status when the temperature
within the protected environment exceeds 58 °C or when the temperature
undergoes anomalous changes.
• "B"; the detector signals alarm status when the temperature within the
protected environment exceeds 72°C.
• "A2S"; the detector signals alarm status when the temperature within in the
protected environment exceeds 58°C .
• "BR"; the detector signals alarm status when the temperature within the
protected environment exceeds 72° or when it senses a rapid temperature
rise.
The operating modes of the "A2S" and "BR" are not certified.
DCMIIN4AID-R100-20110519
Iris
Conventional fire detectors
ID100 - optical smoke detector
ID200 - temperature detector
ID300 - multicriteria detector
Product description
ID100
EN54-7:2000
*00000001*
ID100 00000001 ID100 00000001
ID200
EN54-5:2000
*00000002*
ID200 00000002 ID200 00000002
0832-CPD-1447
0832-CPD-1449
0832-CPD-1445
ATTENTION!
ID100
CONVENTIONAL
2010/09
SMOKE DETECTOR
FW.01.01
0832-CPD-1447
991c/01
00000001
ID200
CONVENTIONAL
2010/09
HEAT DETECTOR
FW.01.01
HEAT DETECTOR CLASS P
0832-CPD-1449
991e/01
00000002
ATTENTION!
