- Page 1 Installation and programming manual EN 50131-1 EN 50131-5-3 EN 50131-4 EN 50130-4 EN 50130-5 CEB T031 Hedera Wireless sounder/flasher for outdoor use Installation and programming manual...
-
Page 2: Table Of Contents
Hedera Wireless sounder/flasher Table of contents Chapter 1 General information......3 About this manual ........3 Manufacturer's details. -
Page 3: Chapter 1 General Information
Web: www.inim.biz The persons authorized by the manufacturer to repair or replace the parts of this system have authorization to work on INIM Electronics brand devices only. Air2 System Description The advanced Air2 two-way wireless intrusion protection system (868MHz frequency) integrates directly with all models in INIM intrusion control panel range. -
Page 4: Chapter 2 Description Of The Sounder/Flasher
Hedera Wireless sounder/flasher Chapter 2 DESCRIPTION OF THE SOUNDER/FLASHER The Hedera outdoor wireless sounder/flasher interfaces with the SmartLiving system via an Air2-BS200 transceiver, which allows the control panel to supervise and control it. The Hedera sounder/flasher can be programmed from the control panel via software which permits the configuration of the various parameters (sound, maximum alarm time, flash rate, signalling activation mode, etc.) and the activation of diverse signals for different events. - Page 5 Installation and programming manual PACKAGE Inside the box you will find: CONTENTS • Hedera sounder/flasher • 2 securing screws for the metal guard • 2 securing screws for the casing • 5 wall plugs for mounting the backplate and tamper bracket •...
- Page 6 Hedera Wireless sounder/flasher Table 3: Technical specifications Warning device type For outdoor use, self-powered, type W type ER34615M 3,6V 13Ah Battery estimated life 3 years (depending on activations) “Low battery” fault voltage Less than 3V during standby 60μA Current draw maximum 600mA Acoustic output type...
-
Page 7: Chapter 3 Sounder/Flasher Functions
Installation and programming manual Chapter 3 SOUNDER/FLASHER FUNCTIONS The Hedera sounder/flasher provides various audible and visual signals. The signals will activate or deactivate in accordance with the programmed settings of the Hedera sounder/flasher or the connected control panel (refer to Chapter 3 - Sounderflasher activations). -
Page 8: Faults And Tampers
Hedera Wireless sounder/flasher Note The event "Open casing" of a Hedera unit does not trigger audible signalling when the connected anti-intrusion control panel is in "Programming" mode. DEACTIVATIONS Signalling will cease when one of the following conditions occurs: • the control panel deactivates it (see above) •... -
Page 9: Chapter 4 Installation And Programming
Installation and programming manual Chapter 4 INSTALLATION AND PROGRAMMING The Ivy unit should be mounted high up on a smooth surface, in such way that it is out of reach but on view and, therefore, may serve as a visible deterrent against break-in. -
Page 10: Programming
Hedera Wireless sounder/flasher Via SmartLeague: 21. Select a sounder/flasher from the those configured in the system tree menu. 22. Access the sounder/flasher “Programming” section then click on the “Wire- less” option check box. 23. Click on the “Enroll” button. The enrollment process window will open. 24. - Page 11 Installation and programming manual 8 modifiable patterns are available: Table 6: Pattern - default Activate Description Activate Sounder Activate Flasher dura- Tone Volume Flash type STATUS LED of pattern sounder duration flasher tion PRG LED Burglary 3 minutes Tone 1 High 3 minutes Burglary low...
-
Page 12: Appendix A Declaration Of Conformity
Hedera Wireless sounder/flasher Appendix A DECLARATION OF CONFORMITY Hereby, INIM Electronics s.r.l. declares that this Air2-Hedera is in compliance with the essential requirements and other relevant provisions of Directive 1999/5/EC. Declarations Performance, Declarations Conformity Certificates concerning to INIM Electronics S.r.l. products may be downloaded free of charge from the web address www.inim.biz, getting access to Extended Access and then... -
Page 13: Appendix B Information About Disposal Of Batteries And Accumulators
Installation and programming manual Appendix B INFORMATION ABOUT DISPOSAL OF BATTERIES AND ACCUMULATORS (Applicable in Countries with separate collection systems) This marking on batteries and/or their manual and/or their packaging, indicates that batteries of these products, at the end of their working life, should not be disposed of as unsorted municipal waste, but must be object of a separate collection. - Page 14 Hedera Wireless sounder/flasher Information about disposal of batteries and accumulators...
- Page 15 Installation and programming manual Notes...
- Page 16 Hedera Wireless sounder/flasher ISO 9001 Quality Management certified by BSI with certificate number FM530352 Centobuchi, via Dei Lavoratori 10 63076 Monteprandone (AP) Italy Tel. +39 0735 705007 _ Fax +39 0735 704912 info@inim.biz _ www.inim.biz...
