- Page 1 ® R&S Power Meter Getting Started (>HÔÔ2) 1424707002...
- Page 2 Rohde & Schwarz GmbH & Co. KG. Trade names are trademarks of the owners. ® 1424.7070.02 | Version 04 | R&S Throughout this manual, products from Rohde & Schwarz are indicated without the ® symbol , e.g. R&S ® NRX is indicated as R&S NRX.
- Page 3 Safety Instructions Instrucciones de seguridad Sicherheitshinweise Consignes de sécurité Risk of injury and instrument damage The instrument must be used in an appropriate manner to prevent electric shock, fire, personal injury or instrument damage. ● Do not open the instrument casing. ●...
- Page 4 Gefahr von Verletzungen und Schäden am Gerät Betreiben Sie das Gerät immer ordnungsgemäß, um elektrischen Schlag, Brand, Verletzungen von Personen oder Geräteschäden zu verhindern. ● Öffnen Sie das Gerätegehäuse nicht. ● Lesen und beachten Sie die "Grundlegenden Sicherheitshinweise", die als gedruckte Broschüre dem Gerät beiliegen. ●...
-
Page 5: Table Of Contents
® Contents R&S Contents 1 Documentation Overview..............5 Getting Started Manual....................5 User Manuals and Help....................5 Tutorials......................... 5 Basic Safety Instructions..................... 5 Data Sheets and Brochures..................5 Release Notes and Open Source Acknowledgment (OSA)........6 Application Notes, Application Cards, White Papers, etc......... 6 2 For Your Safety..................7 3 Key Features...................8 4 Preparing for Use................... - Page 6 ® Contents R&S 5.1.6 USB Host Interface....................... 18 5.1.7 On/Standby Key......................18 Rear Panel Tour......................19 5.2.1 Trig In / Out 2 and Out 1 / Trig Out Connectors............19 5.2.2 Ethernet Interface......................19 5.2.3 USB Device Interface....................20 5.2.4 USB Host Interface....................... 20 5.2.5 AC Supply and Power Switch..................
-
Page 7: Documentation Overview
R&S NRX product page at: www.rohde-schwarz.com/manual/NRX 1.1 Getting Started Manual Introduces the R&S NRX and describes how to set up and start working with the prod- uct. A printed version is delivered with the instrument. 1.2 User Manuals and Help Contains the description of all instrument modes and functions. -
Page 8: Release Notes And Open Source Acknowledgment (Osa)
The open source acknowledgment document provides verbatim license texts of the used open source software. www.rohde-schwarz.com/firmware/NRX 1.7 Application Notes, Application Cards, White Papers, etc. These documents deal with special applications or background information on particu- lar topics. -
Page 9: For Your Safety
The R&S NRX is designated for use in industrial, administrative, and laboratory envi- ronments. Use the R&S NRX only for its designated purpose. Observe the safety and usage instructions documented in the user manual, as well as operating conditions and performance limits stated in the data sheet. -
Page 10: Key Features
® Key Features R&S 3 Key Features The R&S NRX offers the following key features: ● Simple touchscreen operation on a 5" color touchscreen ● Straightforward numerical and graphical display of measured values ● Expandable to up to four measurement channels ●... -
Page 11: Preparing For Use
Check the equipment for completeness using the delivery note and the accessory lists for the various items. Check the R&S NRX for any damage. If there is damage, imme- diately contact the carrier who delivered the R&S NRX. Make sure not to discard the box and packing material. -
Page 12: Important Aspects For Test Setup
Place the R&S NRX on a stable and level surface. The R&S NRX can be used in hori- zontal position, standing on its feet, or with the support feet on the bottom extended. Do not place anything on top of the R&S NRX, if the R&S NRX is not in a level posi- tion. - Page 13 ® Preparing for Use R&S Placing on a Bench Top Risk of injury if feet are folded out The feet can fold in if they are not folded out completely or if the instrument is shifted. Collapsing feet can cause injury or damage the instrument. ●...
-
Page 14: Connecting To The Ac Power Supply
[I]: The instrument is power-supplied. It is either ready for operation (STANDBY) or in operating mode. ► Connect the R&S NRX to the AC power supply, using the power cable that is sup- plied. The R&S NRX complies with safety class EN61010-1. The power supply of the R&S NRX must be connected to a socket with protective conductor. -
Page 15: Connecting Usb And External Devices
1. Press the [on/standby] key. The R&S NRX saves its current settings for reuse in the next session and changes into the standby state. 2. To power down the R&S NRX completely, set the AC power switch to position [0] (Off). Further information: ●... -
Page 16: R&S Nrp-Zxx
5 = Sensor connector of the R&S NRX 6 = R&S NRX Use an R&S NRP‑ZK8 cable to connect an R&S power sensor to the R&S NRX. If you use an R&S NRP‑ZK6 cable, the reference clock and trigger are not supported. -
Page 17: Instrument Tour
Tour......................15 ● Rear Panel Tour...................... 19 5.1 Front Panel Tour Figure 5-1: Front View of R&S NRX 1 = Module bay for optional connectors, see Chapter 5.1.2, "Module Bay", on page 16. 2 = Sensor connectors A and B, see Chapter 5.1.1, "Sensor Connector A and... -
Page 18: Module Bay
See (3) in Figure 5-1. The R&S NRX displays results in panes. Depending on the measurement mode, val- ues are displayed digitally or graphically. False triggers of the touch panel in the presence of static electricity If an object (e.g. a human finger) that is charged with static electricity is brought near the touch panel, false triggers can occur. - Page 19 Pressing [Preset] opens the "Save / Recall / Preset" dialog. If you press [Preset] again, the function "Preset" starts. ● Sets the R&S NRX to its default setting. Default settings are sensor specific. ● Sets the R&S NRX to a setting selected from the recall list.
-
Page 20: Cursor Block
The on/standby key toggles the R&S NRX between standby and ready state. The following states are possible: ● Off (key is not illuminated) The AC power switch on the back of the R&S NRX is switched off. The R&S NRX is disconnected from the AC power supply. ● Ready (green) The R&S NRX is ready for operation. -
Page 21: Rear Panel Tour
By default, the Trig In / Out 2 and Out 1 / Trig Out connectors are disabled. 5.2.2 Ethernet Interface See (2) in Figure 5-2. The Ethernet connector is an RJ45 socket for remote controlling the R&S NRX via a network. Getting Started 1424.7070.02 ─ 04... -
Page 22: Usb Device Interface
Figure 5-2. When the R&S NRX is connected to the AC supply, it automatically sets itself to the correct range for the applied voltage. The range is printed on the type label. There is no need to set the voltage manually. -
Page 23: Sensor Connectors C And D
Rear Panel Tour 5.2.7 Sensor Connectors C and D See (7) Figure 5-2. Requires 3rd and 4th R&S NRP sensor connector (R&S NRX-B4). For more details, see Chapter 5.1.1, "Sensor Connector A and B", on page 15. Getting Started 1424.7070.02 ─ 04... -
Page 24: Index
® Index R&S Index Symbols Interface Ethernet ..............19 1 Trig key ................17 IEC 625/IEEE 488 ............20 Module bay ..............16 USB device ..............20 USB host ..............20 AC power supply ............... 20 Connecting to .............. 12 Accessory list ..............9 Application cards .............. - Page 25 ® Index R&S Trig In / Out 2 BNC connector ........... 19 Tutorials ................5 Unpacking ................9 Device interface ............20 Host interface ............18, 20 User manual ................ 5 White papers ............... 6 Zero key ................17 Getting Started 1424.7070.02 ─ 04...
