Overland Tandberg NEOxl 40 Instructions

Add-on/Spare Power Supply Instructions
This document describes how to either add an optional power
supply or remove and replace an existing power supply in a
NEOxl 40 (3U) tape library from Overland Storage.
WARNING:
To reduce the risk of electric shock or damage to
equipment, always remove any power cords while working with
the library.
WARNUNG: Um das Risiko eines elektrischen Schlags oder
Schäden am Gerät zu vermeiden, ziehen Sie stets den
Netzstecker, bevor Sie an der Einheit arbeiten.
AVERTISSEMENT:
Pour réduire le risque de choc électrique
ou endommagement de l'équipement, retirez toujours les
cordons électriques en travaillant avec l'appareil.
CAUTION:
While working with the library, observe standard
Electrostatic Discharge (ESD) precautions to prevent damage
to micro-circuitry or static-sensitive devices.

Install/Replace Power Supply

Locate and Disconnect the Old Power Supply

To only add a new power supply to a library, skip to
the Cover Plate for the Optional Power
1. Use the OCP or RMI to identify the failed power supply.
2. Locate the failed power supply on the rear of the library
by either the bottom green LED unlit or both LEDs unlit.
3. Unplug the AC power supply cord from the power
supply being replaced.

Remove the Power Supply

1. Finger-loosen the two captive thumbscrews on the
power supply.
2. Using the thumbscrews, slowly pull the power supply
approximately 4 inches (10 cm) out of the library.
3. While using one hand to support the bottom of the power
supply, with the other hand, remove the power supply
from the library.
Proceed to Install New Power
Remove the Cover Plate for the Optional
Power Supply
1. Using a Phillips screwdriver, remove the two screws
securing the power supply cover plate.
2. Set the cover plate aside and save.
10400847-001
Remove
Supply.
Supply.
©2018 Overland Storage, Inc.
NEOxl 40 Tape Library
®
Thumbscrews
Page 1 of 2
