> Prise up the filter cover (1) with a screwdriver and remove from tank.
> Lift out carbon filter (2) and replace.
> Refit filter cover by pressing into place
This kit is required for installation of the lifting system behind a front wall if ventilation
via the roof through an independent vent line is not possible/economical. It contains
all required parts to install the breather and vent with active charcoal filter on the front
wall.
KBN: ABSVIS
NOTE:
The seal for the connection of the vent line to the tank is supplied as standard with
the lifting unit, see point 5.
Changing the carbon filter | ABS front wall installation kit

15. Changing the carbon filter

Figure 10

16. ABS front wall installation kit

1
2
1
