HunterDouglas Provenance Installation Operation Care
Woven wood shades standard cordlock
Hide thumbs
Also See for Provenance:
- Installation operation care (20 pages) ,
- Installation/care (12 pages) ,
- Installation and care instructions (3 pages)
Table of Contents
Advertisement
Quick Links
Advertisement
Table of Contents
Related Manuals for HunterDouglas Provenance
Summary of Contents for HunterDouglas Provenance
- Page 1 Installation Operation Care • • Provenance Woven Wood Shades ® Standard Cordlock...
-
Page 2: Table Of Contents
CONTENTS Getting Started: Product View ...................... 1 Tools and Fasteners Needed ................2 Installation: Installation Overview ................... 3 Mount the Standard Installation Brackets — Inside Mount ........4 Mount the Standard Installation Brackets — Ceiling Mount ........4 Mount the Standard Installation Brackets — Outside Mount ........5 Mount the Turned Headrail ................. -
Page 3: Getting Started
GETTING STARTED Product View Standard Installation Brackets Valance Return* Micropleat Shade Brackets Pull Cord Tassel Attached Matching Fabric Valance Turned Headrail Turned Screws Headrail Option *Valance returns are standard on outside mount shades and optional on inside mount shades. -
Page 4: Tools And Fasteners Needed
GETTING STARTED Thank you for purchasing Hunter Douglas Provenance Woven Wood Shades. With proper ® installation, operation, and care, your new shades will provide years of beauty and performance. Please thoroughly review this instruction booklet and the enclosed packing list before beginning the installation. -
Page 5: Installation
INSTALLATION Installation Overview One of the following bracket types are required depending on shade options ordered. The ■ number of brackets required varies with shade width, as shown in the table below. Brackets Standard Ceiling Extension Micropleat Width Required 18" – 36" "... -
Page 6: Mount The Standard Installation Brackets - Inside Mount
INSTALLATION Mount the Standard Installation Brackets — Inside Mount Mark 1" in from each jamb. ■ If more than two installation brackets came with your order, space additional bracket(s) ➤ evenly between the two end brackets and mark their location. Mount into wood whenever possible. -
Page 7: Mount The Standard Installation Brackets - Outside Mount
INSTALLATION Mount the Standard Installation Brackets — Outside Mount Center the headrail over the window opening at the desired height. Use a pencil to lightly ■ mark each end of the headrail. Alternatively, measure the width of the headrail and use that width to mark the headrail ➤... -
Page 8: Mount The Turned Headrail
INSTALLATION Mount the Turned Headrail Inside/Ceiling Mount Hold the turned headrail in place. ■ Press a headrail screw through each drilled hole in the headrail to ■ mark the screw holes. Drill the screw holes using a " drill bit. ■... -
Page 9: Install The Shade
INSTALLATION Install the Shade If you ordered a Micropleat Liner... Hold the liner so the lift cords ■ Latch Open face you. Close Latch Place the top of the liner headrail up ■ into the bracket. Push up on the headrail and close the ■... -
Page 10: Attach The Optional Components
INSTALLATION Attach the Optional Components If You Ordered Valance Returns... Remove the paper from the pressure sensitive tape ■ Sticky on the valance returns. Smooth the valance down Side the sticky portion of the tape. Valance Return If You Ordered Hold-Down Brackets... Hold-down brackets provide stability and prevent swaying by securing the bottom rail —... -
Page 11: Operation
OPERATION Operate the Shade Standard Shades To raise the shade: Hold the cord and pull until the shade is at the desired ■ height. Pull the cord towards the outside of the shade to lock into ■ position. Unlock To lower the shade: Lock Pull the cord towards the inside of the shade to unlock. -
Page 12: Troubleshooting
OPERATION Troubleshooting Problem The shade will not fit into the installation brackets. Solution Check that the installation brackets are level and aligned. Shim the installation brackets to level the headrail, if necessary. Shims are provided. Be sure the heads of the screws are flush against the installation bracket. Check that the headrail is completely inserted into the installation brackets. -
Page 13: Care
CARE Removing the Shade Standard Shade Fully raise the shade. ■ While holding the headrail, remove each wing nut from all ■ Remove Wing Nut screws on the brackets. If your shade has a turned headrail, remove the screws. Portion of the ➤... -
Page 14: Cleaning Procedures
You may also use a hair dryer on a cool setting or compressed air set to a low pressure. Vacuuming Use a low suction, hand-held vacuum for more thorough dust removal. ■ Spot-Cleaning Only the following Provenance fabrics can be spot-cleaned: ® Adelaide Mindanao ➤... -
Page 15: Child Safety
CHILD SAFETY WARNING For more safety information call 1-888-501-8364 in the U.S. or 1-866-662-0666 in Canada. Child Safety Warning Young children can STRANGLE in cord loops above the cord stop. They can also wrap cords around their necks and STRANGLE. Always keep cords out of the reach of children. - Page 16 If you are not thoroughly satisfied, simply contact Hunter Douglas at (888) 501-8364 or visit hunterdouglas.com. In support of this policy of consumer satisfaction, we offer our Lifetime Limited Warranty as described below.
