Ravaglioli RAV1110K Instructions Manual page 10

P2
P1
RAV1110K/KR
P2
P1
RAV1125
C RIPARTIZIONE DEL CARICO
LOAD DISTRIBUTION
GEWICHT VERTEILUNG
REPARTITION DE CHARGE
REPARTICION DE LA CARGA
P1(P2)
C P1
Q
mm kg
1650
700
1770
800
P2(P1)
1890
900
1000 2100
10
P1
P2
3500 Kg
P1
P2
P2 Q=P1+P2
kg kg
2750
1100
2950
1180
1260 3150
3500
1400
C
Min. 1000mm
0492-M001-2
P2 P1
P1
P2
RAV1120
P2 P1
P1
P2
RAV1125M
2
