S4HVX Shown
H3HX Shown
S4MX Shown
MODELS H3HX, H4HX, S4MX,
S4PX, S4HVX and S4MVX
(Class I, Division 1, Groups C & D): FM
HAZARDOUS LOCATION
SUBMERSIBLE PUMP
(Hazardous Location
INSTALLATION AND SERVICE MANUAL
Motor End)
For use with product built with USEM motor.
NOTE! To the installer: Please make sure you provide this manual to the owner of the equip ment or to the responsible
party who maintains the system.
Item # E-03-487 | Part # 5625-487-1 | © 2018 Pentair plc | 4/16/18
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Pentair Hydromatic H3HX
Summary of Contents for Pentair Hydromatic H3HX
- Page 1 NOTE! To the installer: Please make sure you provide this manual to the owner of the equip ment or to the responsible party who maintains the system. Item # E-03-487 | Part # 5625-487-1 | © 2018 Pentair plc | 4/16/18...
- Page 2 This circuit must be connected to a General Information Pump Installation sensing unit and signaling device. This Attention: Installing Sump Level Controls Float is supplied in a Hydromatic built ® This manual contains important Controls: control panel. information for the safe use of this In either simplex, duplex or triplex NOTE: Failure to install such a product.
- Page 3 IMPORTANT: If equipment is not show high amp draw momentarily, Field Service on Hydromatic properly wired and protected as then as pump comes off start Hazardous Location Pumps: recommended, Hydromatic warranty wirings, amps will drop to normal If a Hydromatic hazardous location is void.
- Page 4 Wiring Diagrams DUAL VOLTAGE 3 PHASE MOTOR WIRING 230V 3ø 460V 3ø GREEN GREEN (L1) (L2) (L3) (L1) (L2) (L3)
- Page 5 H3HX, H4HX, S4MX, S4PX, S4HVX and S4MVX Parts List For use with product built with USEM motor. Ref. Part Part Ref. Part Part Qty. Qty. Description Description 151761005 PG LIFTING BAIL – 180 FRM 000640071 SPRING – BEARING ADJ. 001500191 O-RING –...
- Page 6 Motor Parts Group 10 hp 10 hp 10 hp 10 hp 15 hp 15 hp 15 hp 15 hp Ref. 2 Pole, 3450 RPM 200/3/3450 230/3/3450 460/3/3450 575/3/3450 200/3/3450 230/3/3450 460/3/3450 575/3/3450 Connection Box 114080005 114080015 114080015 114080005 114080025 114080035 114080015 114080005 Rotor/Shaft Assy.
- Page 7 Impeller Parts List Description Volt/ph Impeller Trim 1750 RPM S4MX500BC 200/1 070710152 6.88 S4MX500CC 230/1 070710152 6.88 S4MX500DC 200/3 070710152 6.88 S4MX500EC 230/3 070710152 6.88 S4MX500FC 460/3 070710152 6.88 S4MX500GC 575/3 070710152 6.88 S4MX750CC 230/1 070710232 7.38 S4MX750DC 200/3 070710232 7.38 S4MX750EC 230/3...
- Page 8 Pentair Hydromatic will cover only the lower seal and labor thereof for all dual seal pumps. Under no circumstance will Pentair Hydromatic be responsible for the cost of field labor, travel expenses, rented equipment, removal/reinstallation costs or freight expenses to and from the factory or an authorized Pentair Hydromatic service facility.
