ELECTRIC CHAMFERING TOOL
Please read this manual carefully before you attempt to use
your tool so that you may use it properly and safely.
MINI BEVELER
PROFESSIONAL TOOL
Power Source(Single Phase)
Rated Power Consumption
Rated Duty Cycle
Rated Speed(No Load)
Chamfering Capacity
Chamfering Angle
Mass(Weight)
Sound Pressure Level
Sound Power Level
Vibration Level
Due to continuous product development/improvement the specifications and configurations in this
document are subject to change without prior notice.
Keep the manual handy – so you can use it whenever necessary.
Specifications
Model
Stainless Steel Up to 3mm Chamfer or 2mm, 3mm, 4mm Radius
Mild Steel
Up to 7mm Chamfer or 2mm, 3mm, 4mm Radius
No Load
Load
No Load
Load
Load
Model EMB-0307C
EMB-0307C
115 V AC 50/60 Hz
230 V AC 50/60 Hz
900W
Continue
13300 min
15-45 Degrees
3.9 kg
88 dB(A)
93 dB(A)
99 dB(A)
104 dB(A)
Motor
Knob
Manufactured by :
NITTO KOHKI Co., Ltd.
9-4, NAKAIKEGAMI
2-CHOME, OHTA-KU,
TOKYO, 146-8555, JAPAN
Tel : +81-3-3755-1111
Fax : +81-3-3753-8791
Original Instructions
-1
8.1 m/s
2
2
4.9 m/s
TQ14395-1 05/2017
