User's Manual
Electronic Load
PLZ-5WH2 Series
PLZ1005WH2
PLZ2005WH2
PLZ4005WH2
PLZ12005WH2
PLZ20005WH2
Part No. IB034623
Dec 2019
Contents 6
Component Names 10
Preparation 16
Basic Functions 25
Advanced Functions 65
Sequence Function 89
External Control 108
Parallel Operation 121
System Settings 126
Maintenance 144
Specifications 145
Appendix 160
