Dynojet POWER COMMANDER V Installation Instructions page 3

FIG.A
FIG.B
FIG.C
20-002 www.powercommander.com
1 Remove the seat and fuel tank.
The install can be done without completely removing the fuel tank but the rear of
the tank will at least need to be raised up.
2 Lay the PCV unit near the tool kit temporarily and route the harness down the
right side of the quad. Route the PCV harness underneath the frame cross
member (Fig. A)
3 Unplug the stock wiring harness from the injector (Fig. B).
4 Connect the PCV in-line of the stock wiring harness and the injector (Fig. C).
2009 Suzuki LTZ400 PCV - 3
