Contents
Important User Information . . . . . . . . . . . . . . . . . . . . . . . . . . .2
Safety Precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
Required Tools. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
Hardware Parts List . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
Visit the Legacy Basic web page at www.wengercorp.com for more details.
Note: Please read and understand the instructions before starting the assembly.
Note: If you need additional information, contact Wenger Corporation using the information below.
©Wenger Corporation 2017
Wenger Corporation, 555 Park Drive, P.O. Box 448, Owatonna, Minnesota 55060-0448
Questions? Call.....USA: 800-4WENGER (493-6437) • Worldwide: 1-507-455-4100 • www.wengercorp.com
Legacy
Basic Acoustical Shell
®
Before Assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
Assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
Printed in USA 06/17
Assembly Instructions
Part #186H564-04
Advertisement
Table of Contents
Related Manuals for Wenger Legacy Basic Acoustical Shell
Summary of Contents for Wenger Legacy Basic Acoustical Shell
- Page 1 Visit the Legacy Basic web page at www.wengercorp.com for more details. Note: Please read and understand the instructions before starting the assembly. Note: If you need additional information, contact Wenger Corporation using the information below. ©Wenger Corporation 2017 Printed in USA 06/17 Part #186H564-04 Wenger Corporation, 555 Park Drive, P.O.
- Page 2 Wenger Corporation. Wenger Corporation does not assume any responsibility for any errors that may appear in this manual. In no event will Wenger Corporation be liable for technical or editorial omissions made herein, nor for direct, indirect, special, incidental, or consequential damages resulting from the use or defect of this manual.
- Page 3 Safety Precautions Throughout this manual you may find cautions and warnings which are defined as follows: • WARNING means that failure to follow the instruction may result in serious injury or death. • CAUTION means that failure to follow the instruction may result in serious injury or damage to property.
- Page 4 Assembly 1. Back out the screws and remove the outer lumber and plywood that protect the Legacy Basic during shipping. Do not remove or disassemble the bottom pallet at this time. CAUTION Do not unband the Main Assembly until it is completely assembled and the pallet is removed.
- Page 5 Assembly (continued) 2. Remove the outer-most 4 x 4’s from both sides. If two units are packaged together, remove the outer-most 4 x 4’s from both sides and seperate the pallets. Proceed with assembling each unit separately. Remove Outer 4 x 4’s 3.
- Page 6 Assembly (continued) 5. Remove the two Plug-In Foot Assemblies and Hardware Bag. Set them aside. 6. Unscrew and discard the plywood squares from the pallet. Hardware Plug-In Foot Discard Assemblies Plywood Squares 7. Unscrew and remove the remaining two brackets that secure the back side of the Shell to the pallet.
- Page 7 Assembly (continued) 8. Slide the shell over until the closed side of both feet extend beyond the edge of the pallet. Screw one Caster into the threaded hole on the underside of each foot end. Closed Side Caster Closed Side Caster 9.
- Page 8 Assembly (continued) 10. Using more than one person, carefully slide the shell off of the pallet and onto the floor as shown. CAUTION The Shell is heavy. More than one person is required slide it off of the pallet. 11. Remove any remaining plastic wrapping, banding, tape or packing.
