Wenger Maestro Acoustical Ceiling Installation Instructions Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Contents
Important User Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Safety Precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Before Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Required Tools. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Fasteners. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Ceiling Assembly Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Ceiling Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Mark the Stage Area . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Arrange Ceiling Panels . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Assemble Ceiling Panels . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Attach Ceiling Assembly to Batten . . . . . . . . . . . . . . . . . . . . 17
Fly the Ceiling Assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Level the Ceiling Assembly . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Set the Performance Angle . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Install the Ceiling Catch . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Engage the Ceiling Catch . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Visit the Maestro Acoustical Shell web page at wengercorp.com for more information.
Note: Please read and understand these instructions before using or setting up.
Note: Review all of the Installation Drawings and Reference Drawings.
Note: It is recommended that three or more people work together during the assembly.
Note: If you need additional information, contact Wenger Corporation using the information below.
©Wenger Corporation 2019
Wenger Corporation, 555 Park Drive, P.O. Box 448, Owatonna, Minnesota 55060-0448
Questions? Call.....USA: (800) 4WENGER (493-6437) • Worldwide: +1-507-455-4100 • wengercorp.com
Maestro
®
Ceiling Panel Lights. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Ceiling Panel Light Installation . . . . . . . . . . . . . . . . . . . . . . . 24
Schematics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
LED Ceiling Light Electrical Schematic . . . . . . . . . . . . . . . . . 26
Final Inspection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Printed in USA 2019-09
Installation Instructions
Acoustical Ceiling
Part #201A508-01
