c
ontents
Important User Information . . . . . . . . . . . . . . . . . . . . . . . . . . .2
General . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
Manufacturer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
Intended Use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
Safety Precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
Required Tools . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
Before Assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
Assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
Note: Please read and understand these Assembly Instructions for the Legacy Classic Acoustical
Shell before assembling the parts.
Note: Refer to the illustrations on the following pages. If you need additional information, write or
telephone Wenger Corporation at the number below.
©Wenger Corporation 2011
Wenger Corporation, 555 Park Drive, P.O. Box 448, Owatonna, Minnesota 55060-0448
Questions? Call.....USA: 800-4WENGER (493-6437) • Worldwide: 1-507-455-4100 • www.wengercorp.com
Legacy
Classic Acoustical Shell
®
Printed in USA 10/11
Assembly Instructions
Part #186H191-01
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Wenger Legacy Classic
Summary of Contents for Wenger Legacy Classic
- Page 1 Assembly ........3 Note: Please read and understand these Assembly Instructions for the Legacy Classic Acoustical Shell before assembling the parts.
- Page 2 This is your sole remedy for breach of this warranty. Should you have a question or problem with any Wenger product, don’t hesitate to call, even if the product is past warranty. It’s important to us that all our customers be satisfied.
- Page 3 The following tools are required to assemble the Legacy Classic Acoustical Shell: " Wrench Utility Knife (to cut plastic wrap) • • " Wrench Saw (to cut pallet).
- Page 4 ssembly continued 2. Remove and discard the large piece of protective Protective cardboard from the Main Assembly. Cardboard cAution Do not unband the Main Assembly until it is completely assembled and the pallet is removed. 3. Remove and discard the Support Bracket attached to each Frame Upright.
- Page 5 ssembly continued 4. Remove the two Side Frames from the Counterweight Assembly by cutting the bands securing them. Discard the banding and foam padding. Bands Side frames 5. Attach the Side Frames to the Counterweight Assembly using two -16 x 1" Carriage Bolts and two -16 Hex Nuts in each.
- Page 6 ssembly continued 6. Using assistance, lift the Counterweight Assembly off of the crate and down to the floor. cAution Counterweight Assembly is heavy. Do not attempt to lift without assistance. 7. Move the Counterweight Assembly to the back side of the shell. A lift jack may be used if available.
- Page 7 ssembly continued 9. Use a saw to make a single cut through the pallet as shown below. 10. Remove the four screws securing the Frame to the cut-away section of the pallet. 11. Remove the cut-away section of the pallet. remove Screws Cut-Away...
- Page 8 ssembly continued 13. Repeat steps #9 through #12 for the other side of the shell. Caster Carriage Bolts Hex Nuts 14. Remove the remaining center pallet section. 15. Remove any remaining plastic wrapping, banding, tape or packing.
