Upgrade Procedure
V-Room
to V-Room
Practice
®
®
These instructions cover the installation of Wenger's VAE
®
(Virtual Acoustic Environments) electronics package in previously installed
"V-Ready" installations where the room panels were manufactured without
internal electronic components (Speakers, microphones and VAE control panel).
Contents
Required Tools . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Speaker Installation (4 x 6 Speaker) . . . . . . . . . . . . . . . . . . . . 2
Microphone Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Control Panel Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Black Box Preparation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Black Box Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
©Wenger Corporation 2019
Printed in USA 2019-01
Part #216J510-04
Wenger Corporation, 555 Park Drive, P.O. Box 448, Owatonna, Minnesota 55060-0448
Questions? Call.....USA: (800) 4WENGER (493-6437) • Worldwide: +1-507-455-4100 • wengercorp.com

Advertisement

loading
Need help?

Need help?

Do you have a question about the V-Room and is the answer not in the manual?

Questions and answers

Related Manuals for Wenger V-Room

Summary of Contents for Wenger V-Room

  • Page 1: Table Of Contents

    Black Box Installation ....... 12 ©Wenger Corporation 2019 Printed in USA 2019-01 Part #216J510-04 Wenger Corporation, 555 Park Drive, P.O. Box 448, Owatonna, Minnesota 55060-0448 Questions? Call..USA: (800) 4WENGER (493-6437) • Worldwide: +1-507-455-4100 • wengercorp.com...

  • Page 2: Required Tools

    Required Tools The following tools are required for installation: Cordless Drill Blind Rivet Tool · · · Phillips Drive Bit · " Drill Bit Phillips Screwdriver RH and LH Metal Shears · · Speaker Installation (4 x 6 Speaker) 1. Remove all speaker covers by carefully drilling through the four rivets in each speaker cover with drill bit included in the upgrade kit.

  • Page 3: Microphone Installation

    Microphone Installation 1. Drill out the pop rivets along both sides of the microphone panel with a drill bit no larger than 0.125". Rubber Feet 2. Remove the perforated panel from the wall. 3. Set the switch on the bottom of the microphone housing to the "Flat"...
  • Page 4 Microphone Installation (continued) 7a. If the bracket has one 90 degree bend and one 30 degree bend. Clean the mounting bracket and the back of the microphone plate (in the mounting area) with the alcohol pad. (This must be done or the tape will not stick properly.) Attach mounting tape to microphone bracket located as shown.
  • Page 5 Microphone Installation (continued) 7b. If the bracket has two 90 degree bends. the bracket must be altered to hold the microphone at a 30 degree angle with the microphone’s forward edge approximately centered on the diamond pattern perforations in the interior panel skin. Simply bend the bracket downward approximately 30 degrees as shown until the specified dimension to the bottom of the panel is achieved.

  • Page 6: Control Panel Installation

    Microphone Installation (continued) z8. Place the excess microphone cable behind the fiberglass so it is not visible through the perforations in the interior skin. 9. Position the fiberglass batting around the microphone so as not to be between the end of the microphone and the diamond perforation pattern in the interior skin.
  • Page 7 Control Panel Installation (continued) 4. To accommodate the VAE control panel, the smaller rectangular opening must be enlarged to this new shape. When enlarging the opening, it is important that the bottom edge of both the old and new shapes be in the same place. The blue shape is the pre-Revision H access hole.
  • Page 8 Control Panel Installation (continued) 7. Inside the panel, locate the cable assembly behind the insulation. It will not be used for this installation. It will, however, be used for fishing the new control cable through the power panel and then discarded. 8.

  • Page 9: Black Box Preparation

    Black Box Preparation "Black box" is the term used throughout this manual to describe the assembled black electronics rack containing the VAE processor and related cables and components. 1. Install the flash memory card (connector end first) into the slot in the back of the VAE processor labeled COMPACT FLASH.
  • Page 10 Black Box Preparation (continued) 4. Connect the power cable provided with the VAE processor. It installs between the IEC connector on the back of the VAE processor and the receptacle inside the black box. Bundle and position the excess cable out of the way above the VAE processor.
  • Page 11 Black Box Preparation (continued) Please note before continuing: 6. Most installations will allow the black box to be located in its preferred position on the top of the room. In applications where that space is not available or desirable, the black box can be hung from wall on the side of the room.

  • Page 12: Black Box Installation

    Black Box Installation 1. Position the black box on the room’s roof or sidewall near it’s planned final position. 2. Connect the control cable. This is the cable that extends from the top of the power panel. Insert the connector at the end of this cable into the socket labeled REMOTE KEYPAD on the back of the VAE processor inside the black box.
