c
ontents
Safety Precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
Important User Information . . . . . . . . . . . . . . . . . . . . . . . . . . .3
General . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
Manufacturer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
Intended Use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
Panel Rework . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
Note: Please read and understand these Rework Instructions for the Legacy Panel before
assembling the parts.
Note: Remove all items from the shipping cartons and arrange them in a convenient location.
Refer to the illustrations on the following pages. If you need additional information,
contact the Wenger Corporation using the information below.
©Wenger Corporation 2011
Wenger Corporation, 555 Park Drive, P.O. Box 448, Owatonna, Minnesota 55060-0448
Questions? Call.....USA: 800-4WENGER (493-6437) • Worldwide: 1-507-455-4100 • www.wengercorp.com
Printed in USA 10/11
Rework Instructions
Legacy
Panel
®
Part #186G391-02
Advertisement
Table of Contents
Related Manuals for Wenger Legacy Series
Summary of Contents for Wenger Legacy Series
- Page 1 Refer to the illustrations on the following pages. If you need additional information, contact the Wenger Corporation using the information below. ©Wenger Corporation 2011 Printed in USA 10/11 Part #186G391-02 Wenger Corporation, 555 Park Drive, P.O. Box 448, Owatonna, Minnesota 55060-0448 Questions? Call..USA: 800-4WENGER (493-6437) • Worldwide: 1-507-455-4100 • www.wengercorp.com...
- Page 2 afety Recautions Throughout this manual you mayl find cautions and warnings which are defined as follows. • WarNiNg means that failure to follow the instruction may result in serious injury or death. • CautioN means that failure to follow the instruction may result in serious injury or damage to property.
- Page 3 Wenger Corporation. Wenger Corporation does not assume any responsibility for any errors that may appear in this manual. In no event will Wenger Corporation be liable for technical or editorial omissions made herein, nor for direct, indirect, special, incidental, or consequential damages resulting from the use or defect of this manual.
- Page 4 anel ewoRk 1. Move the Legacy Acoustical Shell and Rework Kit to a flat surface area that has enough space to work in. In addition to the replacement Middle Panel, the kit contains a Hardware pack. Check the contents of the Hardware Pack. It should contain the following: 0.25 x 0.375 x 0.25 Flange Bearings 2 #10-16 x 0.75 Self Drilling Screws 12 1/4-20 x 1 Self Drilling Screws...
- Page 5 anel ewoRk continued 4. Detach the Filler Panel by removing the top row of screws that secure the Hinge to the bottom of the warped Middle Panel. remove top row Secure or have someone hold the of Screws Filler Panel so that it does not drop to the ground when the screws are removed.
- Page 6 anel ewoRk continued 6. Remove the two Alignment Cogs from the top extrusion of the old Middle Panel and attach them to the new Middle Panel using the new #10-16 x 0.75 Self Drilling Screws that are provided. Step 6 alignment Step 7 outer Sets...
- Page 7 anel ewoRk continued 10. From the top outside edge of one Upright Tube, measure down 51¾” (131.5 cm) and mark the location. Align the top edge of the Retrofit Bracket with this mark and check to be sure that the slotted holes are centered on the top half of the Hinge.
- Page 8 anel ewoRk continued 14. Re-attach the Back Cover and Crank Handle that were removed in Step 3. 15. Test the full operation of the entire Acoustical Shell and clean-up as needed.
