Configure Blf; Etension Settings; Phone Settings - Htek UC923 Configuration Manual

Click on Autoprovision Now button.
You'll have to wait couple of seconds for the configuration to be updated.
off your phone.
Auto provisioning process will start during phone reboot process, phone will pickup
appropriate configuration file from PBXware. If everything is done as above described, you
should have successfully registered your phone to PBXware. Dial *123 to verify registration.

Configure BLF

This chapter describes how to configure BLF (Busy Lamp Field) for Htek UC923.
The following topics are covered:
- Extension Settings

- Phone Settings

Etension Settings

Login to PBXware web administration interface.
Open a new browser window and enter the IP address in order to access the PBXware web
administration login page. Example: http://192.168.1.10.
Login to PBXware with your e-mail address and password.
Edit extension.
On the Extensions page click on the edit icon corresponding to your extension.
Click on Advanced Options button.
Navigate down to the Auto Provisioning and Presence group of settings.
Make sure Auto Provisioning is set to Yes.
Make sure Presence is set to "Yes".
Click on the Save button to save changes.
Click on Enhanced services.
Click on Directory / BLF List check box and click on Save button in order to enable this
feature.
Click on Directory / BLF List Edit button.
Enter user extension number and click on the BLF check box.
Click on Save button.
Phone Settings
Login to phone web administration interface.
NOTE:
Do not power
