Summary of Contents for VIRTUFIT Low Entry Bike 1.2i Hometrainer

  • Page 1 Low Entry Bike 1.2i Hometrainer User manual...
  • Page 2 MAINTENANCE TROUBLE SHOOTING TROUBLE SHOOTING 15 - 22 CONTROL PANEL CONTROL PANEL APP INSTRUCTIONS APP INSTRUCTIONS 24 - 25 EXPLODED DRAWING EXPLODED DRAWING 26 - 27 PARTS LIST PARTS LIST TRAINING INSTRUCTIONS TRAINING INSTRUCTIONS VirtuFit Low Entry Bike 1.2i Hometrainer...

  • Page 3: Safety Instructions

    – Before using the device, check that the nuts and bolts are securely tightened. – The safety of the device can only be maintained if it is regularly examined for damage and/or wear and tear. VirtuFit Low Entry Bike 1.2i Hometrainer...
  • Page 4 – Maintenance assembly and repair work not carried out by an official dealer. – In the event of improper use, neglect and / or poor maintenance. – Failure to maintain the device in accordance with the manufacturer’s instructions (see the enclosed manual). VirtuFit Low Entry Bike 1.2i Hometrainer...
  • Page 5 When you open the carton, and you will find the below parts in the carton: NUMBER DESCRIPTION SHAPE Cover Knob M8*30 Bolt M8*73 Arc Washer D8*Φ20 Cap Nut M8*H16 Bolt M8*20*S5 Spring washer D8 Knob M12 VirtuFit Low Entry Bike 1.2i Hometrainer...
  • Page 6 CHECKLIST TOOLKIT NUMBER DESCRIPTION SHAPE Knob M16 Washer D12 Spanner S5 Wrench S13-14-15 VirtuFit Low Entry Bike 1.2i Hometrainer...
  • Page 7 21 - 4PCS B - 1PC • Secure front bottom tube(17) to main frame(16) with bolts(20), arc washers(14) and cap nuts(21). • Secure rear bottom tube(28) to main frame(16) with bolts(20), arc washers(14) and cap nuts(21). VirtuFit Low Entry Bike 1.2i Hometrainer...
  • Page 8 Connect trunk wire 1(15) with trunk wire 2(37). • Insert postbar(2) into main frame(16), then secure them with bolts(12), spring washers(13) and arc washers(14). • Secure pedal(27L/R) to crank(41L/R) by wrench(B). ATTENTION: Tighten the pedals securely. VirtuFit Low Entry Bike 1.2i Hometrainer...
  • Page 9 1(15) with computer wire(1a), then cover end cap(10). • Secure computer(1) on the postbar(2) with screws(11) by wrench(B); • Unlock bolts(94) from postbar(2), then secure bottler holder(93) to postbar(2) with bolts(94) by wrench(B). VirtuFit Low Entry Bike 1.2i Hometrainer...
  • Page 10 Secure saddle(29) in the saddle plate(30) by wrench(B). • Insert the adapter line(38) to power hole on the back of main frame(16), then plug the adapter into an outlet. ATTENTION: Cut off the power source when don’t use it long time. VirtuFit Low Entry Bike 1.2i Hometrainer...

  • Page 11: Adjusting The Saddle

    ADJUSTING THE HANDLEBAR Rotate tension knob (37)clockwise to increase the level of resistance, rotate the tension control counter-clockwise to decrease the level of resistance. Level 1 is the lowest and level 10 is the highest. VirtuFit Low Entry Bike 1.2i Hometrainer...

  • Page 12: Moving The Bike

    To move the machine, push the handlerbar(3) until the transportation wheels(19) on the front bottom tube touch the ground. With the wheels on the ground, you can transport the bike to the desired location with ease. VirtuFit Low Entry Bike 1.2i Hometrainer...

  • Page 13: Daily Maintenance

    • Inspect all bolts and nuts in connection with moving parts of the device, tighten as required. • Check the mobility of moving parts and components of the use equipment, silicone spray if necessary. VirtuFit Low Entry Bike 1.2i Hometrainer...

  • Page 14: Troubleshooting

    The sensors may become damp, dirty or greasy. So you have to clean them regularly. The console is not working If there is no signal when pedaling, check if the cable is properly attached. VirtuFit Low Entry Bike 1.2i Hometrainer...

  • Page 15: Control Panel

    To changeover display WATT or RPM display in the working status ;  .To ENTER choose set items in the stop status needs to be set. DISPLAY-ALT Lets you to select and lock on to a particular function you want. VirtuFit Low Entry Bike 1.2i Hometrainer...
  • Page 16 Keep your hands on the sensor for 3 seconds to display your heart rate. Revolutions per minute. WATTS Displays the wattage. SCAN Functions change automatically every 6 seconds. UNIT HEIGHT WEIGHT DIST WATT PULSE KM / H R / MIN KCAL VirtuFit Low Entry Bike 1.2i Hometrainer...

  • Page 17: Program Settings

    6. If time, distance, calories, or any of these are setting The corresponding value will be inverted in motion status. When any of setting value count to 0, t he motion will be STOP and “DI DI” Voice Prompt. 7. Press “STOP ” key to STOP the motion, in the motio. VirtuFit Low Entry Bike 1.2i Hometrainer...
  • Page 18 3. Press “UP” or “DOWN” key to upward or downward a adjusted, and press “ENTER” key to next item. Press “START” key to starting test and. Hold the pulse sensor. Then the display will show your body fat in 8 seconds later. VirtuFit Low Entry Bike 1.2i Hometrainer...
  • Page 19 < 17% 17% - 23% 23.1% - 25% > 40% B.M.R (BASAL METABOLIC RATE): The average number of calories burned per day for basic survival. • Ref: 1300 ± 100 (22 - 40 years). VirtuFit Low Entry Bike 1.2i Hometrainer...
  • Page 20 7. If time, distance, calories, or any of these are setting. The corresponding value will be inverted in motion status. When any of setting value count to 0, the motion will be STOP and “DI DI” Voice Prompt. VirtuFit Low Entry Bike 1.2i Hometrainer...
  • Page 21 7. If time, distance, calories, or any of these are setting. The corresponding value will be inverted in motion status. When any of setting value count to 0, the motion will be STOP and “DI Voice Prompt. 8. Press “STOP ” key to STOP the motion, in the motion. VirtuFit Low Entry Bike 1.2i Hometrainer...
  • Page 22 Then, it will pop up your pulse recovery level from F1 to F6, that is, from the fastest recovery to slowest. The fastest recovery F1 show the best. RECOVERY 60 SECONDS LATER VirtuFit Low Entry Bike 1.2i Hometrainer...

  • Page 23: App Instructions

    3. Scan the QR code on the right to go to the user manual of the app. The manual describes step by step how the app should be connected to the device, how the app works and what the options are. FITSHOW APP STORE GOOGLE PLAY USER MANUAL FITSHOW FITSHOW FITSHOW VirtuFit Low Entry Bike 1.2i Hometrainer...

  • Page 24: Exploded Drawing

    EXPLODED DRAWING VirtuFit Low Entry Bike 1.2i Hometrainer...
  • Page 25 EXPLODED DRAWING VirtuFit Low Entry Bike 1.2i Hometrainer...
  • Page 26 Wave washer D17 Washer d8*Φ16*1.5 Spacer Φ22*Φ18*4 Nylon nut M8*H7.5*S13 Bolt M6*16 Adjustable footpad φ52*18 Spring washer D6 Nut M8*H5.5*S14 Nylon nut M6 Pedal (L/R) Shaft Rear bottom tube Round magnet Saddle Sensor Saddle plate Motor VirtuFit Low Entry Bike 1.2i Hometrainer...
  • Page 27 Magnetic plate axle Magnetic plate Square magnet Spring Φ1.6*Φ14.5*61*N20 Bolt M6*10 Washer D6*Φ16 Idler Φ39*24 Wave washer D12 Idler rod Washer D12*φ17*0.5 Bolt M8*12 Spring Φ2.0*Φ12.2*62*N20 Power line Bolt M6*45 Nut M6*H5 Washer D6 Knob M8*30 VirtuFit Low Entry Bike 1.2i Hometrainer...

  • Page 28: Training Instructions

    The purpose of cooling down is to return the body to its normal or near normal, resting state at the end of each exercise session. A proper cool-down slowly lowers your heart rate and allows blood to return to the heart. VirtuFit Low Entry Bike 1.2i Hometrainer...
  • Page 29 For questions or missing parts please contact your dealer.
