Summary of Contents for VIRTUFIT Indoor Cycle S2i Spinbike
- Page 1 Indoor Cycle S2i Spinbike User manual...
- Page 2 INDEX 3 - 4 SAFETY INSTRUCTIONS CHECKLIST 6 - 10 ASSEMBLY INSTRUCTIONS 11 - 12 ADJUSTMENTS GUIDE MAINTENANCE TROUBLE SHOOTING 15 - 20 CONTROL PANEL EXPLODED DRAWING PARTS LIST TRAINING INSTRUCTIONS VirtuFit Indoor Cycle S2i Spinbike...
-
Page 3: Safety Instructions
– Ensure there are no children nearby when you are exercising on the device. In addition, the device should be showed in a place that children or house pets cannot reach. – Ensure that only one person at a time uses the fitness device. Virtufit Indoor Cycle S2i Spinbike... -
Page 4: Safety Instructions
– Maintenance assembly and repair work not carried out by an official dealer. – In the event of improper use, neglect and / or poor maintenance. – Failure to maintain the fitness equipment in accordance with the manufacturer’s instructions (see the enclosed manual). VirtuFit Indoor Cycle S2i Spinbike... -
Page 5: Checklist
(4 mm) Semicircular head cross Inner hexagon wrench (5 mm) flower screw M5*16 Inner hexagon wrench Semicircular head cross (6 mm) flower screw M5*20 Semicircular head inner Inner hexagon wrench hexagon screw M10*60 (8 mm) Virtufit Indoor Cycle S2i Spinbike... -
Page 6: Assembly Instructions
STEP 1 • Use the hexagon screw M10 * 60 (A1), washer ø10 (A2), spring washer ø10 (A3), locknut M10 (A4) to attach the front (5) and rear (6) stabilizer to the frame (1). VirtuFit Indoor Cycle S2i Spinbike... - Page 7 ASSEMBLY INSTRUCTIONS STEP 2 • Place the handlebar (8) in the frame (1) and make sure that you adjust it to the correct height. Then connect the wires. Virtufit Indoor Cycle S2i Spinbike...
- Page 8 Place the steering rod (8) in the position as shown in the figure. Use the countersunk head screw M8*16 to attach the handlebar (7) to the handlebar (8). Pay attention! This hex screw is already attached to the steering rod (8). VirtuFit Indoor Cycle S2i Spinbike...
- Page 9 The pedals are marked with “L” (Left) and “R” (Right). Connect them to their correct crank. The judge crank is on the right side of the bicycle when you sit down. Note that the right pedal must are attached clockwise and the left pedal counterclockwise. Virtufit Indoor Cycle S2i Spinbike...
-
Page 10: Assembly Instructions
Insert the adapter line to power hole on the back of main frame (left side), then plug the adapter into an outlet. • Check that all parts / screws are correctly attached and without play. So prevents parts from coming loose. ATTENTION: Cut off the power source when don’t use it long time. VirtuFit Indoor Cycle S2i Spinbike... -
Page 11: Adjustments Guide
FIGURE 6 FIGURE 7 NOTE: When adjusting the upper and lower positions of the handle and the seat, their highest position should not exceed the horizontal “STOP” line as shown in Figure 8. FIGURE 8 Virtufit Indoor Cycle S2i Spinbike... -
Page 12: Adjustments Guide
If you want to stop stop training, you can adjust console to increase resistance or press directly the brakes resistance regulator down until FIGURE 12 crank stops, and then trainer can get off the bike. VirtuFit Indoor Cycle S2i Spinbike... -
Page 13: Daily Maintenance
SEMI-ANNUAL MAINTENANCE • Inspect all bolts and nuts in connection with moving parts of the device, tighten as required. • Check the mobility of moving parts and components of the use equipment, silicone spray if necessary. Virtufit Indoor Cycle S2i Spinbike... -
Page 14: Troubleshooting
• The sensors may have become damp, dirty or greasy, clean them regularly. The console is not working If there is no signal when pedaling, check that the cable is properly attached. VirtuFit Indoor Cycle S2i Spinbike... -
Page 15: Control Panel
Press “START / STOP” to stop or start the workout. STOP RECOVERY Heart Rate Recovery test. UP / DOWN Choose your program or increase / decrease values. MODE Press “MODE” to select a desired function. Virtufit Indoor Cycle S2i Spinbike... - Page 16 6 seconds, a “P” appears on the display. An alarm sounds if your heart rate is higher than your target heart rate. Range: 0-30 ~ 230 BPM. WATT / Shows the training wattage. LOAD VirtuFit Indoor Cycle S2i Spinbike...
-
Page 17: Operation
4. If select BEGINNER function (Figure 9), press MODE confirm to next step.Set BEGINNER1~4 (Figure10), press UP/DOWN to select BEGINNER 1, and press MODE to confirm entering this mode, you can press UP/DOWN button to adjust and set TIME or directly press START button to start workout. After START, Virtufit Indoor Cycle S2i Spinbike... - Page 18 TIME or directly press START button to start workout. After START, press UP and DOWN buttons to adjust motor LOAD. When the graph is executed to the ninth STEP, it is shifted to the left by the scroll bar, and so on. VirtuFit Indoor Cycle S2i Spinbike...
- Page 19 TIME (1~99 minutes) or press START to execute function; After START, according to the WATT value and practice state input by the user, the LEVEL value is automatically adjusted (Figure 21), and the WATT value can be adjusted by pressing the UP or DOWN button. Virtufit Indoor Cycle S2i Spinbike...
-
Page 20: Control Panel
3. Press this KEY after “FX” is displayed ,it returns to normal setting .If press this key again, it will start executing from first item again. 4. Pressing this KEY will be back to normal setting during RECOVERY. FIGURE 22 FIGURE 23 VirtuFit Indoor Cycle S2i Spinbike... -
Page 21: Exploded Drawing
EXPLODED DRAWING Virtufit Indoor Cycle S2i Spinbike... -
Page 22: Parts List
PARTS LIST DESCRIPTION Frame Console Bottle cage Saddle Front foot tube Rear foot tube Handle Handle adjustment Saddle adjustment Pedal Console rear cover Blister bag VirtuFit Indoor Cycle S2i Spinbike... -
Page 23: Training Instructions
The purpose of cooling down is to return the body to its normal or near normal, resting state at the end of each exercise session. A proper cool-down slowly lowers your heart rate and allows blood to return to the heart. Virtufit Indoor Cycle S2i Spinbike... - Page 24 For questions or missing parts please contact your dealer.
