FIGURE 3-8
4. Guide the two top cover plastic tabs in place onto the back panel.
You will hear a click as each tab seats with the back panel (see
5. Use a Phillips screwdriver to reinstall the lock block to the back panel.
FIGURE 3-9
3-10
Sun Ultra 2 UltraSPARC-II Module Upgrade • October 1999
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
Lowering the Cover Onto the System Unit Back Panel
Plastic tab
Cover Tabs and Lock Block
).
FIGURE 3-9
Lock block
Plastic tab
