edition
DH-RP.10
INSTALLATION MANUAL
900-1000kg
** Pictured: RP.10 tail lift
Manufacturer:
DHOLLANDIA N.V.
Zoomstraat 9
9160 LOKEREN (Belgium)
Tel : +32 (0)9 349 06 92
Fax : +32 (0)9 349 09 77
e-mail : info@dhollandia.be
website : www.dhollandia.com
Read the manual in its entirety before operating the tail lift
Keep this manual in the vehicle cab, as reference for the driver and tail lift operator
Doc: FIT_RP.10_CE_EN_2020_rev0
Rev: 0 Date: JANUARY 1, 2020
