INSTALLATION MANUAL
Manufacturer:
DHOLLANDIA N.V.
Zoomstraat 9
9160 LOKEREN (Belgium)
Tel : +32 (0)9 349 06 92
Fax : +32 (0)9 349 09 77
e-mail : info@dhollandia.be
website : www.dhollandia.com
Read the manual in its entirety before operating the lift
Keep this manual in the vehicle cab, as reference for the driver and lift operator
Order ref: xxx Doc: FIT_DH-AI series_CE_EN_2021
Rev: 1 Date: JUL 10, 2021
