SECTION 1 – INSTALLATION
Typical Service Clearances
4 Inch Minimum Clearance
(for Drain Trap)
Return Air
Supply Air
FIGURE 10 - 2–5 TON HORIZONTAL A/C UNIT SERVICE CLEARANCES
20
Front
Evaporator
Fan Access
Evaporator Section
Condenser
Fan Access
36 Inch Minimum Clearance
Condenser
Intake
Condenser Section
36 Inch Minimum Clearance
FORM 145.32-IOM5
ISSUE DATE: 04/08/2019
Condenser
Discharge
LD27701
