SECTION 1 – INSTALLATION
Horizontal
Ductable Ceiling Air Conditioner Packaged Installation
Exhaust
Horizontal
Ductable Ceiling Air Conditioner Split Installation
FIGURE 5 - DUAL COMPRESSOR UNIT – TYPICAL INSTALLATION CONFIGURATION
14
Condenser Section
Outdoor Air
Intake
Floor
Evaporator Section
Return Air
Condenser Section
Return Air
FORM 145.32-IOM5
ISSUE DATE: 04/08/2019
Supply Air
Ceiling
Floor
Evaporator Section
Ceiling
Supply Air
LD27696
