SECTION 1 – INSTALLATION

DIMENSIONAL DATA

4.75
Evaporator
Fan Access
Evaporator Section
Electrical Box Access
Low Voltage
Connection
Condenser
Fan Access
Return Air
Supply Air
NOTES:
1. Dimension tolerance is 1/16 inch
2. Evaporator and condenser duct connections cannot be altered unless noted.
FIGURE 6 - DSH024C AND DSH036C DIMENSIONAL DATA: 2–3 TON HORIZONTAL A/C UNIT
16
Front
Condenser
Fan Access
Condenser Section
Electrical Box Access
Electrical Power
Connection
Back
Evaporator
Fan Access
Optional Return Air (Field
Convertible)
Evaporator
Section
29.00 C.C.
71.88
Front
Front
7.00 17.50
Condenser Openings
25.63
2.70
0.75-inch NPT
Drain Connection
78.19
Optional Condenser
Intake (Field Convertible)
Condenser
Section
38.00 C.C.
FORM 145.32-IOM5
ISSUE DATE: 04/08/2019
26.00 1.00
13.25 7.18
23.75
Evaporator
Openings
Condenser
Intake
Condenser
Discharge
LD27697
