- Page 1 User’s Model SU1004A Manual AQ2160-01 Optical Powermeter IM SU1004A-01E 3rd Edition...
-
Page 2: Table Of Contents
7. Periodic Calibration ････････････････････ 8. Names and Functions of Parts ････････････････････ 9. Attaching the Neck Strap ････････････････････ 10. Operating Procedure ････････････････････ 11. Handling Precautions ････････････････････ 12. If You Suspect a Malfunction ････････････････････ Drawing • Outline drawing of the AQ2160-01 Optical Powermeter ･･････... -
Page 3: Introduction
2. Features of the Instrument The AQ2160-01 is an optical powermeter for measuring optical signal power, and is ideal for performing checks on newly installed optical fibers . The instrument supports wavelengths of 850 nm, 1310 nm, and 1550 nm, and features a backlight, power saving function, and battery charge indicator. -
Page 4: Safety Symbols
If this instrument is used in a manner not specified in this manual, the protective features provided by the instrument may be impaired. Also, Yokogawa assumes no liability for the customer's failure to comply with these requirements. ● The following describes levels of damage that can occur as a result of incorrect operation. - Page 5 ● The following explains warning symbols that must be adhered to. Prohibited (indicates prohibition of a particular action). Indicates that use near Indicates that water, or contact with liquids disassembly is prohibited. (spills, etc.) is prohibited. Indicates that handling with wet hands is prohibited. Required (indicates Indicates that the power...
- Page 6 Do not impair, damage, or attempt to modify the power cord. => Fire or electric shock can result. Never place spent batteries in fire. => Explosion, fire, or burns can result. Do not insert or drop any metal objects into any openings on the instrument, or inside the instrument.
- Page 7 For safety, always unplug the power cord from the outlet during periods of extended non-use. Also, be sure to unplug the power cord from the outlet during lightning storms. => Fire, electric shock, or malfunction can result. Do not use batteries that are not specified for this instrument. Also, do not use old and new batteries at the same time.
- Page 8 If you accidentally drop or damage the instrument, turn OFF the power switch, remove the power plug from the outlet, and contact the dealer from which you purchased the instrument. If the instrument experiences an abnormality, do not attempt to repair the instrument yourself.
-
Page 9: Specifications
6. Specifications * AQ2160-01 Optical Powermeter Specifications Wavelengths 850 nm, 1310 nm, 1550 nm Ref. wavelength 1310 nm Sensor element InGaAs (φ1 mm) Compatible fibers SM (9/125 μm), GI (50/125 μm), GI (62.5/125 μm) fiber Input type SC or FC connector (specify when ordering) Power range -70 dBm–+5 dBm... -
Page 10: Periodic Calibration
Also, the Resume function is not guaranteed to work when the low battery indicator is displayed. 3. When connecting to the AQ2160-01, use a temperature range of 0–+50 °C. However, the safety standard for the AC adapter specifies an operational temperature of 0–40°C. -
Page 11: Names And Functions Of Parts
8. Names and Functions of Parts Optical Input Connector ■ For inputting optical power. Remove the connector cap before making connections. Supports both SC and FC optical connectors. Power Key ■ ● Turning the Power ON When running on battery power, press the key to start up with the Power save function enabled. - Page 12 Power Save Setting Wavelength Setting ■ ■ Displayed when the Power Displays the set wavelength save function is enabled (in nm). Related key: （see “Power key,” page 9） wavelength switching Related key: Power SAVE Units ■ Displays the units of the measured values Low Battery Indicator ■...
-
Page 13: Attaching The Neck Strap
9. Attaching the Neck Strap ■ Attaching the Neck Strap Attach the neck strap by feeding it through the strap attachment holes as shown in the figure. Do not swing the instrument by its strap. Damage or injury can result. Also, when placing the strap around your neck, take care not to choke or strangle yourself. - Page 14 ■ Turning ON the Power ● Starting Up in Power Save Mode Press the key to start the instrument with the power save function ON. ● Starting Up without Power Save Mode If you hold down the key until the power save indicator (PWR SAVE) disappears, the instrument starts with the power save function...
- Page 15 ■ Connecting the Optical Connector Remove the optical connector cap and insert the connector firmly and completely into the connector adapter. If the connection is not sound, measurements will be inaccurate. ● Optical Connector An SC connector and FC connector are available. The desired connector is specified when ordering, and cannot be changed.
- Page 16 ■ Reading the Measured Value SAVE SAVE The figure on the right shows the instrument started up in Power save mode with the wavelength setting set to 1310 nm. The measured value displayed is -14.37 dBm. ■ Using the Backlight Function ●...
-
Page 17: Handling Precautions
11. Handling Precautions The following describes precautions that must be taken during use of the instrument. This instrument utilizes ultra-precision optical components. In order for performance to be guaranteed, please take note of the following. ■ Precautions When Using the Instrument 1) Do not drop or expose the instrument to excessive physical shock. - Page 18 3) Never use an AC adapter or power cable other than the dedicated ones available for use with this instrument, as damage can result. 4) Only use these items indoors. When connecting to the AQ2160-01, use a temperature range of 0–+50 °C (however, the safety standard for...
-
Page 19: If You Suspect A Malfunction
12. If You Suspect a Malfunction The following should be checked if the instrument is not functioning as expected. ■ The instrument doesn’t work even though the power is ON. 1) Are the correct batteries installed? -> Use only AA alkaline dry or nickel metal-hydride rechargeable batteries. -
Page 20: Outline Drawing Of The Aq2160-01 Optical Powermeter
Outline drawing of the AQ2160-01 Optical Powermeter... - Page 21 Product Inquiry For inquiries regarding YOKOGAWA’s measurement instrument products, access “T&M Worldwide Network” on the Web page at the URL indicated below. Then, contact your nearest YOKOGAWA dealer or representative shown on the page. http://www.yokogawa.com/tm/ Printed in Japan...
