  • Page 1 User’s Manual AQ2200 Series Multi Application Test System Startup Guide IM 735101-01EN 13th Edition...
  • Page 2 Product Registration Thank you for purchasing YOKOGAWA products. YOKOGAWA provides registered users with a variety of information and services. Please allow us to serve you best by completing the product registration form accessible from our website. http://tmi.yokogawa.com/ PIM 103-04E...

  • Page 3: List Of Manual

    This user’s manual explains the features, operating procedures, and handling precautions of the AQ2200 Series. To ensure correct use, please read this manual thoroughly before operation. Keep this manual in a safe place for quick reference in the event a question arises.
  • Page 4 YOKOGAWA dealer. • Copying or reproducing all or any part of the contents of this manual without the permission of YOKOGAWA is strictly prohibited. Trademarks • Adobe and Acrobat are registered trademarks or trademarks of Adobe Systems Incorporated.

  • Page 5: Checking The Package Contents

    If the wrong items have been delivered, if items are missing, or if there is a problem with the appearance of the items, contact your nearest YOKOGAWA dealer. When contacting the dealer from which you purchased the instrument, please give them the instrument number.
  • Page 6 Contact your nearest YOKOGAWA dealer to purchase a copy. Optional Accessories (Sold separately) The optional accessories below are available for purchase separately. For information about ordering accessories, contact your nearest YOKOGAWA dealer. Item Model or Part No. Specifications AQ2200-901 blank panel 810518926...
  • Page 7 The English folder in the manual CD contains the PDF files shown below. The CD also contains Japanese manuals. Manual Title Manual No. AQ2200 Series Multi Application Test System IM 735101-01EN User’s Manual Startup Guide AQ2200 Series Multi Application Test System IM 735101-03EN Frame and Module Operation User’s Manual...

  • Page 8: Safety Precautions

    Store this manual in a safe place close to the instrument so that you can refer to it immediately. Keep this manual until you dispose of the instrument. YOKOGAWA assumes no liability for the customer’s failure to comply with these requirements. The following symbols are used on this instrument.
  • Page 9 Doing so is extremely dangerous. Do Not Remove the Covers or Disassemble or Alter the Instrument Only qualified YOKOGAWA personnel may remove the covers and disassemble or alter the instrument. The inside of the frame controller is dangerous because parts of it have high voltages.
  • Page 10 Safety Precautions Avoid Electric Shock When Using the Modules Do not apply an input voltage that exceeds the maximum input voltage, withstand voltage, or allowable surge voltage. To prevent the possibility of electric shock, be sure to fasten the screws that are at the bottom of the front panel of 2-slot and 3-slot modules.
  • Page 11 Cela pourrait être extrêmement dangereux. Ne pas retirer le capot, ni démonter ou modifier l’instrument Seul le personnel YOKOGAWA qualifié est habilité à retirer le capot et à démonter ou modifier l’instrument. Certains composants à l’intérieur de l’instrument sont à...
  • Page 12 Safety Precautions Installer et utiliser l’instrument aux emplacements appropriés • Ne pas installer, ni utiliser l’instrument à l’extérieur ou dans des lieux exposés à la pluie ou à l’eau. • Installer l’instrument de manière à pourvoir immédiatement le débrancher du secteur en cas de fonctionnement anormal ou dangereux.
  • Page 13 Safety Precautions AQ2200-111, AQ2200-141, AQ2200-142, and AQ2200-136 Modules Laser Class 1M Label Using an optical instrument, such as a loupe, magnifying glass, or microscope, when observing the laser beam from a distance of less than 100 mm may cause eye injury. Do not expose users of binoculars or telescopes.

  • Page 14: Sales In Each Country Or Region

    Authorized Representative in the EEA Yokogawa Europe B.V. is the authorized representative of Yokogawa Test & Measurement Corporation for this product in the EEA. To contact Yokogawa Europe B.V., see the separate list of worldwide contacts, PIM 113-01Z2 About Environmental Standard This instrument complies with environmental standard EN50581, but it will not comply with the standard if an incompliant module is installed.

  • Page 15: Symbols And Notation Used In This Manual

    Symbols and Notation Used in This Manual Notes and Cautions The notes and cautions in this manual are categorized using the following symbols. Improper handling or use can lead to injury to the user or damage to the instrument. This symbol appears on the instrument to indicate that the user must refer to the user’s manual for special instructions.

  • Page 16: Table Of Contents

    Contents List of Manual.............................i Checking the Package Contents...................... iii Safety Precautions ........................... vi Sales in Each Country or Region ....................xii Symbols and Notation Used in This Manual .................. xiii Module Model Name, Suffix Code, and Accessories ..............xvi Chapter 1 Component Names and Functions Frame Controller ......................
  • Page 17 Contents Chapter 4 Troubleshooting, Maintenance, and Inspection Troubleshooting ........................ 4-1 Error Messages ........................ 4-6 Changing Modules ......................4-16 Updating the Firmware ....................4-19 Routine Maintenance ..................... 4-27 Recommended Replacement Parts ................4-34 Calibration ........................4-35 Disposing of the Instrument .................... 4-35 Chapter 5 Specifications AQ2211/AQ2212 Frame Controller ..................

  • Page 18: Module Model Name, Suffix Code, And Accessories

    Module Model Name, Suffix Code, and Accessories AQ2200-111 DFB-LD Module Model Suffix Code Description 810518901 — Wavelength -Mxxxx See section 5.2 for the list of supported wavelengths -W1310 1310 nm -W1490 1490 nm Optical connector -FCA FC/Angled PC connector Optical output level -P10 10 mW optical output -P20...
  • Page 19 Module Model Name, Suffix Code, and Accessories AQ2200-141 FP-LD Module Model Suffix Code Description 810518902 — Wavelength -W1310 1310 nm -W1550 1550 nm Optical connector /FCC AQ9441 (FC) universal adapter /SCC AQ9441 (SC) universal adapter Standard Accessories The standard accessories below are supplied with the instrument. Item Model or Part No.
  • Page 20 Module Model Name, Suffix Code, and Accessories AQ2200-131 Grid TLS Module (-T2 and -T4:Firmware version 3.00 and later) (-T6:Firmware version 3.05 and later) Model Suffix Code Description AQ2200131 — Wavelength C-band L-band LD type Standard type Advanced type (Fine tuning) Advanced type (Fine tuning) Optical fiber PM fiber...
  • Page 21 Module Model Name, Suffix Code, and Accessories AQ2200-201 Interface Module Model Suffix Code Description 810518905 — Standard Accessories The standard accessories below are supplied with the instrument. Item Model or Part No. Quantity Notes Analog out plug 955-230002662 Optical sensor head 955-850002026 connector cable User’s manual...
  • Page 22 Module Model Name, Suffix Code, and Accessories AQ2200-231 Optical Sensor Head Model Suffix Code Description 810518906 Large-aperture, long-wavelength sensor Connector adapter /FCC AQ9355C (FC) connector adapter with a light shielding cap /SCC AQ9335C (SC) connector adapter with a light shielding cap /STC AQ9335C (ST) connector adapter with a light shielding cap Standard Accessories...
  • Page 23 Module Model Name, Suffix Code, and Accessories AQ2200-232 Optical Sensor Head (Firmware version 3.05 and later) Model Suffix Code Description AQ2200232 Large-aperture, long-wavelength sensor Connection cable Length: 1 m Length: 4 m Connector adapter /FCC AQ9355C (FC) connector adapter with a light shielding cap /SCC AQ9335C (SC) connector adapter with a light shielding cap /LCC...
  • Page 24 Module Model Name, Suffix Code, and Accessories AQ2200-241 Optical Sensor Head Model Suffix Code Description 810518907 Large-aperture, short-wavelength sensor Connector adapter /FCC AQ9355C (FC) connector adapter with a light shielding cap /SCC AQ9335C (SC) connector adapter with a light shielding cap /STC AQ9335C (ST) connector adapter with a light shielding cap Standard Accessories...
  • Page 25 Module Model Name, Suffix Code, and Accessories AQ2200-242 Optical Sensor Head (Firmware version 3.06 and later) Model Suffix Code Description AQ2200242 Large-aperture, short-wavelength sensor Connection cable Length: 1 m Length: 4 m Connector adapter /FCC AQ9355C (FC) connector adapter with a light shielding cap /SCC AQ9335C (SC) connector adapter with a light shielding cap /LCC...
  • Page 26 Module Model Name, Suffix Code, and Accessories AQ2200-211 Sensor Module Model Suffix Code Description 810518908 Highly sensitive, long-wavelength sensor Connector adapter /FCC AQ9447 (FC) connector adapter with a light shielding cap /SCC AQ9447 (SC) connector adapter with a light shielding cap /STC AQ9447 (ST) connector adapter with a light shielding cap Standard Accessories...
  • Page 27 Module Model Name, Suffix Code, and Accessories AQ2200-215 Sensor Module Model Suffix Code Description 735125 High power sensor Connector adapter -NON No connector adapter -FCC AQ9335C (FC) connector adapter with a light shielding cap -SCC AQ9335C (SC) connector adapter with a light shielding cap -STC AQ9335C (ST) connector adapter with a light shielding cap -LCC...
  • Page 28 Module Model Name, Suffix Code, and Accessories AQ2200-221 Sensor Module Model Suffix Code Description 735122 Two-channel, long-wavelength sensor Connector adapter -NON No connector adapter -FCC AQ9335C (FC) connector adapter with a light shielding cap -SCC AQ9335C (SC) connector adapter with a light shielding cap -STC AQ9335C (ST) connector adapter with a light shielding cap -LCC...
  • Page 29 Module Model Name, Suffix Code, and Accessories AQ2200-311 ATTN Module Model Suffix Code Description 810518915 — Optical connector -FCC FC/PC connector -SCC SC/PC connector -FCA FC/Angled PC connector -SCA SC/Angled PC connector Monitor port option /MON Monitor port included Standard Accessories The standard accessories below are supplied with the instrument.
  • Page 30 Module Model Name, Suffix Code, and Accessories AQ2200-331 ATTN Module Model Suffix Code Description 735133 Built-in monitor power meter Optical fiber MMF (GI 50/125) MMF (GI 62.5/125) Optical connector -FCC FC/PC connector -SCC SC/PC connector Standard Accessories The standard accessories below are supplied with the instrument. Item Model or Part No.
  • Page 31 Module Model Name, Suffix Code, and Accessories AQ2200-411 OSW Module Model Suffix Code Description 735141 1×4 or 1×8 Port configuration 1×4 1×8 Optical fiber MMF (GI 50/125) MMF (GI 62.5/125) Optical connector -FCC FC/PC connector -SCC SC/PC connector Standard Accessories The standard accessories below are supplied with the instrument.
  • Page 32 Module Model Name, Suffix Code, and Accessories AQ2200-601 10 Gbit/s BERT Module Model Suffix Code Description 810518801 — Options PC software for creating 64 Mbit program patterns PC software for creating SDH/SONET frame patterns Standard Accessories The standard accessories below are supplied with the instrument. Item Model or Part No.
  • Page 33 Module Model Name, Suffix Code, and Accessories AQ2200-631 10 Gbit/s Optical Receiver Model Suffix Code Description μ 810518803 1.31/1.55 Optical connector SC connector FC connector Cable U-link coaxial cable Standard Accessories The standard accessories below are supplied with the instrument. Item Model or Part No.

  • Page 34: Chapter 1 Component Names And Functions

    Front Display screen Displays settings and measured results. Soft keys Module installation slots Used when you control the Hold AQ2200 series modules. frame controller or a module. AQ2211 FRAME CONTROLLER USB Port (type A) Used when you connect a USB...
  • Page 35 1.1 Frame Controller Nine-Slot Type Front Soft keys Used when you control the frame controller or a module. Display screen Displays settings and measured results. Module installation slots Hold AQ2200 series modules. AQ2212 FRAME CONTROLLER SLOT SLOT DETAIL SUMMARY HOLD...
  • Page 36 1.1 Frame Controller Display and Key Operation Console Display Displays information such as measured values, settings, and status. AQ2211 FRAME CONTROLLER Soft keys The soft keys are used to select and execute the items that are shown on the display. Arrow keys ◄...
  • Page 37 1.1 Frame Controller SUMMARY Screen The SUMMARY screen displays the information from all the installed modules at once. You can view the main parameters, and confirm and change all the parameters. • Current module: Module with a blue background. You can change this module’s parameters. The parameters that you can change are displayed as soft keys.

  • Page 38: Light Source Modules

    Light Source Modules AQ2200-111 DFB-LD Module AQ2200-111 DFB-LD Lock lever MODULE Lock lever release button Used when installing and Releases the lock lever. uninstalling the module. Modulation indication lamp Laser output indication lamp The lamp is lit when the laser output The lamp is lit when the laser output CHOP modulation is set to CHOP.
  • Page 39 1.2 Light Source Modules AQ2200-112 LS Module Firmware version 3.08 and later 1-Channel Model Lock lever Lock lever release button Used when installing and Releases the lock lever. uninstalling the module. OUTPUT1 key Turns the OUTPUT1 laser output on or off. Laser output (OUTPUT1) Transmits the laser beam.
  • Page 40 1.2 Light Source Modules AQ2200-141 FP-LD Module AQ2200-141 FP-LD Lock lever release button Lock lever MODULE Releases the lock lever. Used when installing and uninstalling the module. Modulation indication lamp Laser output indication lamp The lamp is lit when the laser output The lamp is lit when the laser output modulation is set to CHOP.
  • Page 41 1.2 Light Source Modules AQ2200-131 Grid TLS Module -T2, -T4: Firmware version 3.00 and later -T6: Firmware version 3.05 and later Lock lever Lock lever release button Used when installing and Releases the lock lever. uninstalling the module. OUTPUT1 key Turns the OUTPUT1 laser output on or off.
  • Page 42 1.2 Light Source Modules AQ2200-136 TLS Module Lock lever release button Releases the lock lever. AQ2200-136 TLS MODULE Lock lever Used when installing and uninstalling the module. Laser output indication lamp The lamp is lit when the laser output is on. OPT key Turns the laser output on and off.

  • Page 43: Optical Sensor Modules

    Optical Sensor Modules AQ2200-201 Interface Module AQ2200-201 INTERFACE MODULE Lock lever Lock lever release button Used when installing and uninstalling Releases the lock lever. the module. Modulation indication lamp The lamp is lit when the light Analog signal output terminal modulation is set to CHOP.
  • Page 44 1.3 Optical Sensor Modules AQ2200-231/ 241 Optical Sensor Head Interface module connector You can use a cable to connect the optical sensor head to an AQ2200-201 interface module. Mounting screw hole Optical input The mounting screw hole is used The optical input receives optical signals. to fix the unit in place.
  • Page 45 1.3 Optical Sensor Modules AQ2200-211 Sensor Module (Highly sensitive type) Lock lever release button Lock lever Releases the lock lever. Used when installing and uninstalling the module. Modulation indication lamp The lamp is lit when the light Analog signal output terminal modulation is set to CHOP.
  • Page 46 1.3 Optical Sensor Modules AQ2200-221 Sensor Module (Dual) Lock lever Lock lever release button Used when installing and Releases the lock lever. uninstalling the module. Optical input (device 1) This optical input receives an optical signal. Use an AQ9335C connector adapter when connecting an optical fiber.

  • Page 47: Orl Module

    ORL Module AQ2200-271 ORL Module AQ2200-271 Lock lever MODULE Lock lever release button Used when installing and Releases the lock lever. uninstalling the module. ANGLED PC*ONLY MEAS Light measurement Connects to the DUT,* the optical return loss of which is being measured.

  • Page 48: Attenuator Modules

    Attenuator Modules AQ2200-311 ATTN Module AQ2200-311 ATTN MODULE Lock lever release button Lock lever Releases the lock lever. Used when installing and uninstalling the module. Optical output indication lamp ENABLE The lamp is lit when the optical output is on. DISABLE ENABLE/DISABLE key Turns the optical output on and off.
  • Page 49 1.5 Attenuator Modules AQ2200-312 ATTN Module Firmware version 3.04 and later AQ2200-312 ATTN Lock lever release button MODULE Lock lever Releases the lock lever. Used when installing and uninstalling the module. OUTPUT Output key Turns the optical output on and off. The key is lit when the optical output is on.
  • Page 50 1.5 Attenuator Modules AQ2200-332 ATTN Module (Built-in monitor power meter) Firmware version 3.04 and later AQ2200-332 ATTN Lock lever MODULE Lock lever release button Used when installing and Releases the lock lever. uninstalling the module. OUTPUT OUTPUT key Turns the optical output on and off. The key is lit when the optical output is on.

  • Page 51: Optical Switch Modules

    Optical Switch Modules AQ2200-411 OSW Module 1×4 Type AQ2200-411 Lock lever MODULE Lock lever release button Used when installing and Releases the lock lever. uninstalling the module. Common port (A) Connected to the port that is selected from select port 1 to select port 4.
  • Page 52 1.6 Optical Switch Modules AQ2200-412 OSW Module 1×16 Type AQ2200-412 Lock lever MODULE Lock lever release button Used when installing and Releases the lock lever. uninstalling the module. Common port (A) Connected to the port that is selected from select port 1 to select port 16.
  • Page 53 1.6 Optical Switch Modules AQ2200-421 OSW Module 1×2 Type AQ2200-421 Lock lever release button Lock lever MODULE Releases the lock lever. Used when installing and uninstalling the module. DVC1 DVC2 Common port (A) Common port (A) Device 1 Device 2 Connected to the port that is Connected to the port that is selected from select port 1...

  • Page 54: Bert Module

    BERT Module AQ2200-601 10 Gbit/s BERT Module Signal output indication lamp This lamp shows the status of the PPG signal output.The lamp is lit when the output is on. Signal output ON/OFF key Turns all of the PPG output terminals on or off at once. Lock lever release button Each time this key is pressed, signal output switches Releases the lock lever.

  • Page 55: Optical Modulator Modules

    Optical Modulator Modules AQ2200-621 10 Gbit/s Optical Modulator (Wavelength: 1.55 μm) Lock lever Lock lever release button Used when installing and Releases the lock lever. uninstalling the module. Data input terminal Data input terminal. Use a U-link (/U option) or coaxial cable to connect this terminal to the DATA OUT (TO OPTICAL MODULATOR) Laser input terminal...

  • Page 56: Optical Receiver Module

    Optical Receiver Module AQ2200-631 10 Gbit/s Optical Receiver CAUTION Use an optical ATT to protect the terminal if there is a chance that the input level of the 10 Gbit/s optical signal that will be applied to the optical input terminal (OPT IN) will exceed the maximum input power (6 dBm).

  • Page 57: Xfp Interface Module

    1.10 XFP Interface Module AQ2200-641 XFP Interface Module CAUTION If an XFP transceiver is not installed, cover the DATA IN and DATA IN input terminals with the included protective caps. French ATTENTION En l’absence d’émetteur-récepteur XFP, couvrir les bornes d’entrée DATA IN et DATA IN à...

  • Page 58: Transceiver I/F Module

    1.11 Transceiver I/F Module AQ2200-642 Transceiver I/F Module Lock lever release button Releases the lock lever. Lock lever Used when installing and uninstalling the module. AQ2200-642 TRANSCEIVER I/F MODULE Signal output indication lamp This lamp shows the status of OUTPUT the power supply to the transceiver.

  • Page 59: Sg Module

    1.12 SG Module AQ2200-651 SG Module Lock lever release button Releases the lock lever. Lock lever Used when installing and uninstalling the module. AQ2200-651 SG MODULE Signal output indication lamp RF OUT This lamp shows the status of the OUTPUT clock signal output (RF OUT).

  • Page 60: Chapter 2 Making Preparations For Measurements

    Unplug If Abnormal Behavior Occurs If you notice smoke or unusual odors coming from the instrument, immediately turn off the power and unplug the power cord. Then, contact your nearest YOKOGAWA dealer. Do Not Damage the Power Cord Nothing should be placed on top of the power cord, and it should be kept away from any Index heat sources.
  • Page 61 2.1 Handling Precautions Module Handling Precautions • Do not expose the modules to excessive shock. • Do not remove the module cases. • Do not touch the metal parts of the module connectors with your hands. CAUTION Do not carry the AQ2211 or AQ2212 Frame Controller while modules are installed in the instrument.

  • Page 62: Installing The Instrument

    Installing the Instrument Installation Conditions Install the instrument in a place that meets the following conditions. WARNING • Do not install the instrument outdoors or in locations subject to rain or water. • Install the instrument so that you can immediately remove the power cord if an abnormal or dangerous condition occurs.
  • Page 63 2.2 Installing the Instrument Well-Ventilated Location Inlet holes are located on the right and bottom of the instrument. There are also exhaust holes on the rear side. To prevent internal overheating, allow for enough space around the instrument (see the figure below), and do not block the inlet and exhaust holes. 5 cm or more 5 cm or more 10 cm or more...
  • Page 64 2.2 Installing the Instrument Rack Mounting To rack-mount the instrument, use the separately sold rack mount kit. Product Name Model AQ2211 rack mount kit (for mounting one AQ2211 to an EIA-standard rack) 735182-03 AQ2212 rack mount kit (for mounting one AQ2212 to an EIA-standard rack) 735182-09 An outline of the mounting procedure is given below.
  • Page 65 2.2 Installing the Instrument • Rack-Mounting to the AQ2211 Frame Controller Cover stickers Bracket Small binding screws Cover sticker Small binding screws Cover stickers Bracket • Rack-Mounting to the AQ2212 Frame Controller Cover stickers Small binding screws Bracket Cover stickers Cover stickers Small binding screws Bracket...

  • Page 66: Attaching And Removing Blank Panels

    Attaching and Removing Blank Panels WARNING To prevent electric shock, and to ensure that the instrument performs within its specifications, be sure to cover any unused slots with the blank panels sold separately. If you use the instrument without covering empty slots with blank panels, the instrument may malfunction due to dust getting inside of it or its internal temperature rising.
  • Page 67 2.3 Attaching and Removing Blank Panels Attaching a Blank Panel Align the protrusion at the top of the blank panel such that it catches on the top part of the frame controller slot. Fasten the blank-panel screw into the screw hole on the bottom part of the frame controller slot.

  • Page 68: Installing And Uninstalling Modules

    Installing and Uninstalling Modules WARNING • Do not apply a voltage that exceeds the maximum input voltage, withstand voltage, or allowable surge voltage. • Be sure to fasten the screws that are at the bottom of the front panel of 2-slot and 3-slot modules.
  • Page 69 2.4 Installing and Uninstalling Modules Installing a Module While pressing the button on the module panel, pull up on the lever. Lever Button Note When inserting a module, always check its vertical orientation. Align the groove on the bottom of the module with the guide on the slot that you want to install the module into, and slowly insert the module into the frame controller.
  • Page 70 2.4 Installing and Uninstalling Modules Uninstalling a Module If you are uninstalling a two-slot or three-slot module, loosen the fixing screws. Note The modules are constructed so that the fixing screws do not fall out. While pressing the button, lightly pull the lever up until it unlocks. Button Lever Index...

  • Page 71: Connecting Cables

    Connecting Cables How to Connect the Optical Sensor Head and Interface Module Connecting a Cable Insert the cable connector into the connector on the front of the interface module (make sure that the guide pin of the connector on the module fits into the groove of the cable connector), and then tighten the screw to secure them.
  • Page 72 2.5 Connecting Cables How to Connect Cables for BER Measurement CAUTION • Be sure to attach terminators to any unused output terminals. Terminators are attached to the module terminals by factory default. • When making connections to I/O terminals, use a grounding strap or other method to prevent electrostatic discharge.
  • Page 73 2.5 Connecting Cables Not Using the CDR Function through the Electrical Interface Make the following connections if the DUT will not use the CDR function of the BERT module through the electrical interface. DATA IN2 DATA CLOCK OUT CLOCK IN Phase Phase shifter...
  • Page 74 Using the Optical Interface Make the following connections when the DUT has the optical interface and you are using a combination of a BERT module (BERT) , an AQ2200 series light source module (LS) , an optical modulator module (EO)
  • Page 75 2.5 Connecting Cables Using an External SG Make the following connections to use an external SG (signal generator). See “Using the CDR Function through the Electrical Interface,” “Not Using the CDR Function through the Electrical Interface,” and “Using the Optical Interface,” for instructions on how to make connections to the DUT.
  • Page 76 2.5 Connecting Cables Using the Trigger Terminal • Using the Trigger Terminal to Generate Trigger Signals for Waveform Monitoring Make the following connections if you want to use the trigger terminal to generate trigger signals for an oscilloscope. DATA OUT CLOCK OUT Oscilloscope TRIGGER OUT...
  • Page 77 2.5 Connecting Cables Using the Trigger Terminal to Generate the Reference Clock of an Optical Transceiver Make the following connections if you want to use the trigger terminal to generate the reference clock of an optical transceiver. U-link (coaxial) U-link (coaxial) BERT DATA OUT DATA IN...
  • Page 78 2.5 Connecting Cables Using the Trigger Terminal to Generate a Reference Clock for Synchronizing Multiple Instruments Make the following connections if you want to use the trigger terminal to synchronize multiple instruments. MASTER SLAVE TRIGGER OUT REF CLK IN Index Coaxial cable Using the XFP Interface Make the following connections between the BERT and the XFP interface if you want to...
  • Page 79 2.5 Connecting Cables Connecting Cables When connecting this instrument to the DUT, to another module, or to a measuring instrument, take appropriate measures to protect the instrument from static electricity. CAUTION Before attaching and detaching cables or terminators to this instrument’s connectors, ground the instrument or connect the operator to a metallic part of the main frame to protect against static electricity.

  • Page 80: Connecting And Disconnecting Connector Adapters

    Connecting and Disconnecting Connector Adapters By changing the connector adapter, you can connect the light source modules (AQ2200- 141 and AQ2200-142) and sensor modules to a variety of optical connectors. How to Connect and Disconnect the AQ9447 Connector Adapter The AQ9447 Connector Adapter can be used with the AQ2200-211 sensor module. Connecting the Adapter Fit the guide pins of the connector adapter into the guide holes on the rear shell.
  • Page 81 2.6 Connecting and Disconnecting Connector Adapters How to Connect and Disconnect the AQ9441 Universal Adapter The AQ9441 Universal Adapter can be used with the AQ2200-141 FP-LD and AQ2200- 142 DUAL FP-LD modules. Connecting the Adapter Fit the guide pins of the universal adapter into the guide holes on the rear shell. Take care not to let the universal adapter come in contact with the end of the ferrule that extends from the rear shell.
  • Page 82 2.6 Connecting and Disconnecting Connector Adapters How to Connect and Disconnect the AQ9335C Connector Adapter The AQ9335C Connector Adapter can be used with the AQ2220-231 Optical Sensor Head, AQ2220-232 Optical Sensor Head, AQ2200-241 Optical Sensor Head, AQ2200-242 Optical Sensor Head, AQ2200-215 Sensor Module, and AQ2200-221 Sensor Module. Connecting the Adapter Fit the guide holes of the connector adapter onto the guide pins on the rear shell.

  • Page 83: Connecting Optical Fiber Cables

    Connecting Optical Fiber Cables CAUTION Only connect angled-physical-contact type optical fibers to the ANGLED PC ONLY optical connector. Other types of connectors can damage the connector’s ferrule end. French ATTENTION Ne brancher que des fibres optiques de type APC (contact physique avec angle) au connecteur optique ANGLED PC ONLY.

  • Page 84: Connecting To The Power Supply

    Connecting to the Power Supply Before Connecting the Power Supply Make sure to follow the warnings below when connecting the power supply. Failure to do so may cause electric shock or damage to the instrument. WARNING • Make sure that the power supply voltage matches the instrument’s rated supply voltage and that it does not exceed the maximum voltage range of the power cord to use.
  • Page 85 2.8 Connecting to the Power Supply Connecting the Power Cord Check that the power switch is off. Connect the power cord plug to the power inlet on the rear panel. Connect the other end of the cord to an outlet that meets the following conditions. Use a grounded three-prong outlet.
  • Page 86 The power cord is securely connected. • The correct voltage is coming to the power outlet (see the previous page). If the instrument still does not work properly, contact your nearest YOKOGAWA dealer for repairs. • Depending on the type and number of modules that are installed in the frame controller, it may take some time for the startup screen to appear.

  • Page 87: Chapter 3 External Input And Output

    Chapter 3 External Input and Output Frame Controller Interlock (REMOTE INTERLOCK) CAUTION Only apply signals that meet the specifications. Doing otherwise may damage the instrument. French ATTENTION N’appliquer que des signaux correspondant aux spécifications. pour éviter d’endommager l’instrument. Interlock Connector Index The frame controller is equipped with an interlock terminal as a laser output safety device.
  • Page 88 3.1 Frame Controller External Trigger Input Terminal This terminal receives external trigger signals for starting measurements on sensor modules. Item Specifications Connector type Input level TTL level μ Input pulse width s or more Input impedance Approx. 5 kΩ Trigger Out (TRIGGER OUT) CAUTION Do not apply an external voltage to the TRIGGER OUT terminal.

  • Page 89: Optical Sensor Modules

    Optical Sensor Modules Analog Out (ANALOG OUT) Analog Signal Output Terminal This terminal transmits a voltage level that corresponds to the level of the optical signal that is applied to the sensor. Use cables that are 3 m or shorter in length. Other than AQ2200-202 ANALOG OUT Item...

  • Page 90: Bert Module

    BERT Module CAUTION This precision measuring instrument handles high-speed signals at a rate of 10 Gbit/s. If the following precautions are not observed strictly, the instrument will not be able to deliver its maximum performance and may malfunction. • Before removing modules from the frame controller, turn the output off. •...
  • Page 91 3.3 BERT Module • Ne pas laisser les bornes de sortie DATA OUT, DATA OUT, CLOCK OUT et CLOCK OUT ouvertes. Toujours les raccorder à des charges de 50 Ω, telles que les bornes incluses. De même, toujours raccorder les câbles connectés à ces bornes de sortie à...
  • Page 92 3.3 BERT Module Clock Signal Output Terminals (CLOCK OUT and CLOCK OUT) These terminals transmit 10 GHz non-inverted and inverted clock signals respectively. Item Specifications Connector type SMA, female Output level 0.6 Vp-p (typical) AC-coupling Offset voltage –2 to +3 V (in 10 mV steps) Ω...
  • Page 93 3.3 BERT Module External Clock Signal Input Terminal (EXT CLOCK IN) If you want to operate the BERT module with an external clock signal at a rate of 10 GHz, without using the internal SG, apply a 10 GHz clock signal to this terminal. Item Specifications Connector type...

  • Page 94: Optical Modulator Module

    Optical Modulator Module CAUTION • When connecting a cable to the data input terminal, use a grounding strap to prevent electrostatic discharge. If the cable is charged with static electricity, the instrument may malfunction. Always connect cables after they have been discharged.

  • Page 95: Optical Receiver Module

    Optical Receiver Module CAUTION • When connecting a cable to the data output terminal, use a grounding strap to prevent electrostatic discharge. If the cable that you are connecting is charged with static electricity, the instrument may malfunction, so always connect cables after they have been discharged.

  • Page 96: Xfp Interface Module

    XFP Interface Module CAUTION • Before connecting cables to or disconnecting cables from the I/O terminals, turn the output off. • Before connecting cables to the I/O terminals, tighten the connectors at a specified torque using a torque wrench. • Do not leave the data and clock output terminals open. Always terminate them with 50 Ω...
  • Page 97 3.6 XFP Interface Module • Toujours brancher les connecteurs aux bornes d’E/S de manière droite et non inclinée pour éviter d’endommager ces dernières ou d’endommager les fils des connecteurs. • Ne pas appliquer de tension externe aux bornes de sortie. External Clock Input Terminal (REF CLOCK IN) If you want to synchronize the XFP interface module with an external clock signal and use the module to operate a transceiver, apply a reference signal that has a frequency...

  • Page 98: Transceiver I/F Module

    Transceiver I/F Module CAUTION • Always use the specified connector to connect this module’s I/O terminals. Using unspecified connectors to connect the I/O terminals may cause damage to the terminals and the connectors. • Before connecting cables to or disconnecting cables from the connectors, turn the output off.
  • Page 99 3.7 Transceiver I/F Module POWER SUPPLY Port (POWER SUPPLY) Provides power to the transceiver. POWER SUPPLY 28W MAX D-Sub 25-pin receptacle Item Specification Index Connector type D-SUB 25 pin Maximum power output 28 W Pin No. Signal Specifications Pin No. Signal Specifications 5.250 V, 1 A/pin...
  • Page 100 3.7 Transceiver I/F Module Control/Monitor Signal Port (SIGNAL) Use to configure the transceiver control signal or monitor the power supply voltage and status signals. SIGNAL VHDCI 68-pin receptacle Pin No. Signal Specification Pin No. Signal Specification — — CTRL17(3.3V) O 3.3 V CMOS 1.2 V CMOS —...

  • Page 101: Sg Module

    SG Module CAUTION • Before removing modules from the frame controller, turn the output off. • Before turning the frame controller off, turn the output off. • Before connecting cables to or disconnecting cables from the I/O terminals, turn the output off. •...
  • Page 102 3.8 SG Module Clock Signal Output (RF OUT CH1 to CH5) Transmits a 622 MHz (output rate: 1/1) or 155 MHz (output rate: 1/4) clock signal. Item Specification Connector type SMA, female Output amplitude 0.8 Vp-p ± 0.2 Vp-p, 1.3 Vp-p ± 0.2 Vp-p Frequency 620.0 to 720.0 MHz (when the rate is 1/1) 155.0 to 180.0 MHz (when the rate is 1/4)

  • Page 103: Chapter 4 Troubleshooting, Maintenance, And Inspection

    • If a message appears on the screen, see the following pages for reference. • If servicing is necessary, or if the instrument does not operate properly even after you have attempted to deal with the problem according to the instructions in this section, contact your nearest YOKOGAWA dealer. Problem Probable Cause...
  • Page 104 4.1 Troubleshooting Problem Probable Cause Corrective Action Reference Section The output waveform The cables are not connected Check that the cables are connected. If they are Section 2.5 is not clear. well. loose, connect them firmly. (BERT module) Unused output terminals are not Check the output terminals.
  • Page 105 4.1 Troubleshooting BER Measurements (With clock recovery) This test inspects whether the SG-PPG-ED (CDR) module is operating properly by looping the signal from the PPG back to the ED and performing BER measurements. • Procedure Insert a 10 dB attenuator in the DATA IN 1 terminal (with built-in CDR) of the AQ2200-601 10 Gbit/s BERT module’s ED, and use a coaxial cable to connect this terminal to the DATA OUT terminal of the PPG.
  • Page 106 4.1 Troubleshooting BER Measurements (Without clock recovery) This test inspects whether the SG-PPG-ED (without CDR) module is operating properly by looping the signal from the PPG back to the ED and performing BER measurements. • Procedure Insert a 10 dB attenuator in the DATA IN 2 terminal (without CDR) of this instrument’s ED, and use a coaxial cable to connect this terminal to the DATA OUT terminal of the PPG.
  • Page 107 If the cause of the problem cannot be located, or if the instrument cannot be returned to its original state, contact your nearest YOKOGAWA dealer. Check the following before you contact your nearest YOKOGAWA dealer. Instrument Name The instrument name is shown on the nameplate that is on the rear of the frame controller or on the side of a module.

  • Page 108: Error Messages

    Messages may appear on the screen while you are using this instrument. This section describes the error messages and the corrective action to take. If the corrective action states that serving is required, contact your nearest YOKOGAWA dealer. In addition to the messages listed here, other communication-related error messages may also appear.
  • Page 109 Hardware failed, and The system is malfunctioning. Servicing is required. needs to be repaired. Please contact Yokogawa’s representatives. Incorrect date and time The date and time settings are Configure the date and time correctly. setting. Set the correct date incorrect.
  • Page 110 There is a discrepancy between the Update the firmware on the frame controller and version of the firmware installed in the module. Contact your local YOKOGAWA dealer the frame controller and the firmware for the latest version of the firmware.
  • Page 111 4.2 Error Messages LS Module (AQ2200-112) Available in firmware versions 3.08 and later Code Error Message Description Corrective Action 1100 LS Lock Laser output is locked. Attach an interlock connector to the rear of the frame controller. If the same message continues to appear, set Lock to Off on the frame controller’s SYSTEM screen.
  • Page 112 4.2 Error Messages TLS Module Code Error Message Description Corrective Action 1130 Temperature The temperature inside the module is Turn the power off and confirm that the frame controller’s inlet Error too high. and exhaust holes are not blocked. After waiting for some time, restart the instrument.
  • Page 113 No. for sensor head. If the same message continues to appear, servicing is required. Contact your local YOKOGAWA dealer for the latest version of the firmware. 1260 PD Module Error1 The Peltier temperature is abnormal. Turn the power off and confirm that the frame controller’s inlet and exhaust holes are not blocked.
  • Page 114 4.2 Error Messages OSW Module Code Error Message Description Corrective Action 1401 Temperature Error The internal temperature is too Turn the power off and confirm that the frame controller’s inlet high. and exhaust holes are not blocked. After waiting for some time, restart the instrument.
  • Page 115 4.2 Error Messages XFP Interface Module Code Error Message Description Corrective Action 1600 Memory Check An error occurred during the start- Restart the instrument. If the same message continues to Error up memory check. appear, servicing is required. 1601 Flash Rom Write An error occurred during writing to Restart the instrument.
  • Page 116 4.2 Error Messages Transceiver I/F Module Code Error Message Description Corrective Action 1700 Temperature Error The internal temperature is too Turn the power off, and confirm that the frame controller's high. ventilation holes are not blocked. After waiting for some time, restart the instrument.
  • Page 117 4.2 Error Messages 10Gbit/s BERT Module Code Error Message Description Corrective Action 2011 Command Error Commend error Check the command and send it again. 2012 Range Error A parameter was set that does not Check the parameter. Set the wavelength to a value that falls fall within the settable range.

  • Page 118: Changing Modules

    Changing Modules You can install and uninstall modules while the frame controller is on. Uninstalling a Module You can uninstall modules while the instrument is on. Uninstall the module that is installed in slot 3. Note When you remove the module while displaying a screen other than the DETAIL or SUMMARY screen, the screen closes and the DETAIL or SUMMARY screen appears.
  • Page 119 4.3 Changing Modules Installing a Module You can install modules while the instrument is on. When a module is installed, the instrument automatically detects it. If the module is not automatically detected, follow the procedure below to force the instrument to detect the installed modules. Install the module in an empty slot.
  • Page 120 4.3 Changing Modules After the instrument finishes detecting the modules, the DETAIL or SUMMARY screen appears. A module has been detected Note • An error message may appear immediately after the instrument finishes detecting the installed modules. This error shows that, due to a discrepancy between the release version of the firmware installed in the frame controller and the firmware installed in the module, there is a possibility that some operations may not work properly.

  • Page 121: Updating The Firmware

    Updating the Firmware CAUTION • After you update the firmware on an instrument, all of its settings are reset to their initial values. Where necessary, save the settings before you update the firmware. • If you do not comply with the following precautions you will not be able to restart the instrument.
  • Page 122 4.4 Updating the Firmware Turn the instrument on while holding down the top soft key. The update screen appears, and the instrument begins updating the firmware automatically. Top soft key << Update Firmware >> Updating... Boot Rev. : 1.01-00 FPGA1 Rev. : 0.06-00 Progress S .
  • Page 123 4.4 Updating the Firmware Press the Close soft key to close the SOFTWARE VERSION screen. Updating the Module Firmware Update Procedure Connect a USB memory device that contains the most recent version of the firmware to the front of the frame controller. Note Index •...
  • Page 124 4.4 Updating the Firmware Press the Update Exec soft key to update the firmware for the selected modules. Executing Note If you select multiple modules to update, the progress indication is updated for each module. One of the following four progress indications is displayed. •...
  • Page 125 4.4 Updating the Firmware Displaying Instrument Information Displaying Frame Controller Information You can display the frame controller’s hardware and firmware information. Follow the steps below to display this information. Press SYSTEM to display the SYSTEM screen. Use the arrow keys to select Information, and press the Select soft key or ENTER.
  • Page 126 4.4 Updating the Firmware Press the Information soft key to display the Module Information screen. The display will be slightly different depending on the installed modules. Head Info Module Info Soft key menu for interface modules • Displaying Interface Module Device Information Press the Module Info soft key to display the Module Information screen.
  • Page 127 When you update the module firmware or purchase a newly released module, be sure to also update the frame controller firmware. You can download the latest firmware from the YOKOGAWA website if you register as a user.
  • Page 128 Displaying Instrument Information The instrument information appears in the following formats. The details are different depending on the instrument. Frame Controller Item Description Display Example PRODUCT Manufacturing company YOKOGAWA MODEL CODE Model 735101 SERIAL NO. Serial number 00001 OPTION Options...

  • Page 129: Routine Maintenance

    Routine Maintenance Notes before Storage Wipe the instrument off with a cloth to remove dust, fingerprints, and other dirt. For instructions on how to clean the exterior of the instrument, see “Cleaning the Frame Controller and Modules.” Carry out the condition check (fan alarm) and key check to confirm that the instrument operates correctly.
  • Page 130 4.5 Routine Maintenance Why It Is Necessary to Clean the Optical Interface The optical connectors and optical plugs are the only optical components whose optical fiber end faces are exposed to the outside. Even a tiny scratch on their end faces that cannot be detected by the naked eye greatly affects their optical performance.
  • Page 131 4.5 Routine Maintenance Correctly aligned optical connectors Center axes are misaligned Center axis The center axis is misaligned because of this piece of dust. Optical connectors whose axes are Index misaligned due to a piece of dust 4-29 IM 735101-01EN...
  • Page 132 4.5 Routine Maintenance Tools Required for Cleaning Optical Interfaces When cleaning an optical interface, prepare the following: • Isopropyl alcohol • Cleaning paper • Stick-type cleaners • Compressed air • An optical connector end face magnifying microscope WARNING Do not clean optical connectors or optical adapters while the laser beam is being generated.
  • Page 133 4.5 Routine Maintenance How to Clean the AQ9441 and AQ9335C Optical Connector Adapters Soak a stick-type cleaner in the isopropyl alcohol, and slowly insert it into the optical connector adapter’s precision sleeve. Use the stick-type cleaner to clean the adapter’s inner walls. Wipe of the moisture with another stick-type cleaner.
  • Page 134 4.5 Routine Maintenance How to Clean the Optical Output Connector of the AQ2200-141 and AQ2200-142 FP-LD Modules Soak a piece of cleaning paper in the isopropyl alcohol, and rub the cleaning paper against the ferrule end face. Wipe of the moisture with another piece of cleaning paper. After that, use the compressed air to remove any remaining dust.
  • Page 135 4.5 Routine Maintenance CAUTION Wipe the light receiving glass softly. Strong pressure may scratch the glass or break the components. French ATTENTION Nettoyer avec précaution le verre récepteur de lumière. Toute pression forte risque de rayer le verre ou de casser les composants. How to Clean the Optical I/O Connectors of the AQ2200-131/132 Grid TLS Module How to Clean the Optical I/O Connectors of the AQ2200-136 TLS Module See “How to Clean the Optical Output Connector of the AQ2200-111 DFB-LD Module...

  • Page 136: Recommended Replacement Parts

    Recommended Replacement Parts The following parts are susceptible to wear. We recommend replacing them at the following intervals. For part replacement, contact your nearest YOKOGAWA dealer. Part Name Recommended Notes Replacement Interval Cooling fan 40000 hours Lithium battery 3 years...

  • Page 137: Calibration

    To maintain consistent performance, calibrate and adjust the instrument once every six months. If YOKOGAWA calibrates the instrument, we can also perform adjustments as requested. If you calibrate the instrument, you can adjust it by entering the correction values that you obtained from the calibration into the instrument’s CAL_Offset...

  • Page 138: Chapter 5 Specifications

    Chapter 5 Specifications AQ2211/AQ2212 Frame Controller Performance and Functional Specifications Item Specifications Number of slots AQ2211: 3 AQ2212: 9 Display Color LCD, 320 × 240 dots Storage USB storage USB Mass Storage Class flash memory. See “USB (for peripheral devices).” Output format Setup parameters Proprietary format...
  • Page 139 5.1 AQ2211/AQ2212 Frame Controller General Specifications Item Specifications Operating environment Ambient temperature: 5 to 40°C Ambient humidity: 20 to 80% RH (no condensation) Altitude: 2000 m or less Storage environment Ambient temperature: –20 to 60°C Ambient humidity: 20 to 80% RH (no condensation) Altitude: 3000 m or less Recommended calibration period 1 year (including installed modules)
  • Page 140 5.1 AQ2211/AQ2212 Frame Controller 3 The 735101 and 735102 do not comply with environment regulation standard EN50581:2012 when following modules are installed. Model No Module Name/Application Name 810518901 AQ2200-111 DFB-LD Module AQ2200131-T4 AQ2200-131 Grid TLS Module(suffix code is -T4 (standard) model) AQ2200132-T4 AQ2200-131 Grid TLS Module(suffix code is -T4 (standard) model)

  • Page 141: Aq2200-111 Dfb-Ld Module

    AQ2200-111 DFB-LD Module Performance and Functional Specifications Item Specifications Center wavelength 1310 nm, 1490 nm: ±10 nm 1524.111 to 1620.500 nm: As stated in the table of supported wavelengths Specifiable wavelength range 1310, 1490, and 1524.111 to 1620.500 nm Wavelength accuracy 2, 17 1310 nm, 1490 nm: ±0.05 nm or less 1524.111 to 1620.500 nm: ±0.02 nm or less...
  • Page 142 5.2 AQ2200-111 DFB-LD Module General Specifications Item Specifications Operating conditions The same as the frame controller’s operating environment Temperature and humidity for storage Ambient temperature: –20 to +60°C Ambient humidity: 20 to 80% RH (no condensation) External dimensions 31 (W) × 117 (H) × 321.5 (D) mm (excluding protrusions; one slot) Weight Approx.
  • Page 143 5.2 AQ2200-111 DFB-LD Module DFB-LD Module Table of Supported Wavelengths Optical frequency: THz, Wavelength: nm Wavelength Optical Wavelength Wavelength Optical Wavelength Wavelength Optical Wavelength Code Frequency Code Frequency Code Frequency M0290 191.60 1564.679 M0085 193.55 1548.915 M0480 195.50 1533.465 M0275 191.65 1564.271 M0100...

  • Page 144: Aq2200-112 Ls Module

    AQ2200-112 LS Module Firmware version 3.08 and later Performance and Functional Specifications Item Specifications Number of channel 1 or 2 channel Device type DFB-LD 1, 2, 3, 5 Center wavelength 1310 nm ± 5 nm 1550 nm ± 5 nm 1625 nm ±...

  • Page 145: Aq2200-141/142 Fp-Ld Module

    AQ2200-141/142 FP-LD Module Performance and Functional Specifications Item Specifications AQ2200-141 AQ2200-142 Center wavelength 1, 2 1310 ± 20 nm (when 1310 nm is specified) 1310 ± 20 nm, 1550 ± 20 nm 1550 ± 20 nm (when 1550 nm is specified) Applicable optical fiber SM (ITU-T G.652) 1, 2, 3...

  • Page 146: Aq2200-131/132 Grid Tls Module

    AQ2200-131/132 Grid TLS Module -T2/-T4: Firmware version 3.00 and later -T6: Firmware version 3.05 and later Performance and Functional Specifications Item Specifications Suffix code -T2/-T6 Suffix code -T4 Number of channel C, L-Band 1 (AQ2200-131) or 2 (AQ2200-132) Device type C, L-Band Advanced type Standard type Frequency (Wavelength) range...
  • Page 147 5.5 AQ2200-131/132 Grid TLS Module After 30 minutes warm up. The environmental conditions are subject to the specification of frame controller, unless otherwise specified 1 When a PM fiber is used. 2 Advanced type: At grid mode on, A grid spacing is except a manual setting. 3 Ambient temperature: 23 ±...

  • Page 148: Aq2200-136 Tls Module

    AQ2200-136 TLS Module Performance and Functional Specifications Item Specifications Variable wavelength width 1440 to 1640 nm Wavelength setting resolution 1 pm 1, 2 Absolute wavelength accuracy ≤ ±100 pm 1, 2 Relative wavelength accuracy ≤ ±50 pm Wavelength stability (over time) ±5 pm/h 4, 8, 10 Spectrum line width...

  • Page 149: Aq2200-201 Interface Module

    AQ2200-201 Interface Module Performance and Functional Specifications Item Specifications Number of channels One AQ2200-231 or AQ2200-241 can be connected. Analog output Ambient temperature: –20 to +60°C Outpu voltage range Approx. 0 to 2 V Output impedance Approx. 1 kΩ Connector type Mini plug General Specifications Item...

  • Page 150: Aq2200-202 Interface Module

    AQ2200-202 Interface Module Performance and Functional Specifications Item Specifications Number of channels Up to two AQ2200-232 or AQ2200-242 can be connected. • When AQ2200-232 is connected: Available in the frame controller’s firmware version 3.05 and later • When AQ2200-242 is connected: Available in the frame controller’s firmware version 3.06 and later and AQ2200-202’s firmware version 2.00 and later Analog output...

  • Page 151: Aq2200-231/241 Optical Sensor Head

    AQ2200-231/241 Optical Sensor Head Performance and Functional Specifications Item Specifications AQ2200-231 AQ2200-241 Photo sensor element InGaAs, 5 mm diameter Si, 10 mm diameter Measurement wavelength range 800 to 1700 nm 400 to 1100 nm Power range CW light: –90 to +10 dBm CHOP light: –90 to +7 dBm Minimum display resolution 1/10000...
  • Page 152 5.9 AQ2200-231/241 Optical Sensor Head 3 Reference conditions: • Power level: 100 μW (–10 dBm), CW light • Wavelength: 850 ± 10 nm • Light source spectrum width: 10 nm or less • Ambient temperature: 23 ± 2°C • Optical fiber: SM (ITU-T G.652) •...

  • Page 153: Aq2200-232/242 Optical Sensor Head

    5.10 AQ2200-232/242 Optical Sensor Head Performance and Functional Specifications Item Specifications AQ2200-232 AQ2200-242 Number of channels Photo sensor element InGaAs, 5 mm diameter Si, 5.8 mm × 5.8 mm Measurement wavelength range A800 to 1700 nm 400 to 1100 nm 1, 2 Power range –90 to +15 dBm...
  • Page 154 5.10 AQ2200-232/242 Optical Sensor Head 6 Operating conditions for the AQ2200-232: • Power level: 1 nW to 10 mW (–60 to +10 dBm), CW light • Wavelength range: 1000 to 1630 nm • Optical fiber: ≤ GI 50 μm, NA ≤ 0.2 (add ±1% if GI 62.5 μm and NA ≤ 0.275) •...

  • Page 155: Aq2200-211 Sensor Module

    5.11 AQ2200-211 Sensor Module Performance and Functional Specifications Item Specifications Photo sensor element InGaAs Measurement wavelength range 700 to 1700 nm Power range CW light –110 to +10 dBm CHOP light –110 to +7 dBm Minimum display resolution 1/10000 Applicable optical fiber ≤...
  • Page 156 5.11 AQ2200-211 Sensor Module * All values in the specifications assume a warm-up period of one hour. 1 Reference conditions: • Power level: 100 μW (–10 dBm), CW light • Wavelength: 1310 ± 20 nm • Light source spectrum width: 10 nm or less •...

  • Page 157: Aq2200-215 Sensor Module

    5.12 AQ2200-215 Sensor Module Performance and Functional Specifications Item Specifications Photo sensor element InGaAs Measurement wavelength range 970 to 1660 nm Power range –70 to +30 dBm Minimum display resolution 1/10000 Applicable optical fiber ≤ 62.5/125 μm (GI), NA ≤ 0.275 Uncertainty at reference conditions ±3% 2, 7...
  • Page 158 5.12 AQ2200-215 Sensor Module * All values in the specifications assume a warm-up period of one hour. 1 Reference conditions: • Power level: 100 μW (–10 dBm), CW light • Wavelength: 1310 ± 20 nm • Light source spectrum width: 10 nm or less •...

  • Page 159: Aq2200-221 Sensor Module

    5.13 AQ2200-221 Sensor Module Performance and Functional Specifications Item Specifications Photo sensor element InGaAs, 3 mm diameter Measurement wavelength range 800 to 1700 nm Power range –70 to +10 dBm Minimum display resolution 1/10000 Applicable optical fiber ≤ 62.5/125 μm (GI), NA ≤ 0.275 Uncertainty at reference conditions ±3% Total uncertainty...
  • Page 160 5.13 AQ2200-221 Sensor Module * All values in the specifications assume a warm-up period of one hour. 1 Reference conditions: • Power level: 100 μW (–10 dBm), CW light • Wavelength: 1310 ± 20 nm • Light source spectrum width: 10 nm or less •...

  • Page 161: Aq2200-271 Orl Module

    Compliant measurement connector AC/Angled PC 1 Depends on the wavelength of the light source used 2 23 ± 2°C when using a reference reflector and a YOKOGAWA-specified master cord at the Fresnel reflection reference. During use after calibration. 3 ±2 σ...

  • Page 162: Aq2200-311 Attn Module

    5.15 AQ2200-311 ATTN Module Performance and Functional Specifications Item Specifications Wavelength range 1200 to 1700 nm Insertion loss 1.0 dB (typical) 1, 2, 3, 4 1.6 dB or less 1, 2, 3 Maximum attenuation 60 dB 2, 3, 5, 6 Attenuation accuracy ±...

  • Page 163: Aq2200-311A/312 Attn Module

    Wavelength: 1310 ± 15 nm, 1550 ± 15 nm Ambient temperature: 23 ± 2°C (constant temperature) When using the Yokogawa reference master cord (SMF) Connectors not included Wavelength: 1550 ± 15 nm 0.15 dB or less if the wavelength is 1310 ± 15 nm 2 σ...

  • Page 164: Aq2200-331/332 Attn Module

    Wavelength: 1310 ± 15 nm or 1550 ± 15 nm Ambient temperature: 23 ± 2°C (constant temperature) When using the Yokogawa reference master cord (SMF) Connectors not included. 2.3 dB or less when connectors are included. Wavelength: 1550 ± 15 nm 0.15 dB or less if the wavelength is 1310 ±...

  • Page 165: Aq2200-342 Dual Attn Module

    All values in the specifications assume a warm-up period of one hour. Wavelength: 1550 ± 15 nm Ambient temperature: 23 ± 2°C (constant temperature) When using the Yokogawa reference master cord Polarization dependence is not included. 1 minutes later after the attenuation setting 2 σ...

  • Page 166: Aq2200-411/412 Osw Module

    1 Wavelength: 1310 ± 15 nm or 1550 ± 15 nm 2 Wavelength: 850 or 1300 nm 3 Ambient temperature: 23 ± 2°C (constant temperature) 4 When using the Yokogawa reference master cord (SMF) 5 Connectors not included. 1.4 dB or less when connectors are included. 6 2 σ...

  • Page 167: Aq2200-421 Osw Module

    1 Wavelength: 1310 ± 15 nm or 1550 ± 15 nm 2 Wavelength: 850 or 1300 nm 3 Ambient temperature: 23 ± 2°C (constant temperature) 4 When using the Yokogawa reference master cord (SMF) 5 Connectors not included. 1.4 dB or less when connectors are included. 6 2 σ...

  • Page 168: Aq2200-601 10 Gbit/S Bert Module

    5.21 AQ2200-601 10 Gbit/s BERT Module Performance and Functional Specifications Item Specifications Pulse Pattern Generator Interface Data output Bitrate 9.95 to 11.32 Gbit/s (DATA OUT and Data format DATA OUT) Output amplitude 0.5 to 2.0 Vp-p (in 10 mV steps) Tr/Tf (20 to 80%) 25 ps or less Offset voltage...
  • Page 169 5.21 AQ2200-601 10 Gbit/s BERT Module Item Specifications Clock and Common Interface Operation clock Clock mode Internal clock (Internal), external reference clock (REF Clk), and external clock (EXT Clk) Internal clock Frequency range 9.95 to 11.32 GHz Resolution 1 kHz External reference Input frequency 1/16 or 1/64 of the bitrate...
  • Page 170 5.21 AQ2200-601 10 Gbit/s BERT Module Item Specifications Error Detector Data Receive pattern PRBS 2n-1 (n: 7, 9, 10, 11, 15, 23, or 31) PROGRAM Standard: 16 to 256 bits (in 1-bit steps) Optional: 256 to 67108864 bits (in 128-bit steps) SDH/SONET Optional Descramble: Fixed to ON...

  • Page 171: Aq2200-621/622 10 Gbit/S Optical Modulator

    5.22 AQ2200-621/622 10 Gbit/s Optical Modulator Performance and Functional Specifications Item Specifications Wavelength range AQ2200-621: 1530 to 1570 nm AQ2200-622: 1290 to 1330 nm Wavelength variation As stated in the specifications for the AQ2200-111 DFB-LD module Optical power variation As stated in the specifications for the AQ2200-111 DFB-LD module LN Cut type X-cut or Z-cut Optical insertion loss...

  • Page 172: Aq2200-631 10 Gbit/S Optical Receiver

    5.23 AQ2200-631 10 Gbit/s Optical Receiver Performance and Functional Specifications Item Specifications Wavelength range 1290 to 1330 nm or 1530 to 1570 nm Minimum optical receiving sensitivity 1, 2 < –15 dBm at 1550 nm, Ex = 12 dB, 9.953 Gbit/s, PRBS31 <...

  • Page 173: Aq2200-641 Xfp Interface Module

    5.24 AQ2200-641 XFP Interface Module Performance and Functional Specifications Item Specifications Data input Data format Connector 3.5 mm, female (DATA IN, DATA IN) Data output Data format Connector 3.5 mm, female (DATA OUT, DATA OUT) Reference clock input Input level 0.6 Vp-p ±...

  • Page 174: Aq2200-642 Transceiver I/F Module

    5.25 AQ2200-642 Transceiver I/F Module Monitoring Specifications Name Rating Measurement Range Accuracy Upper Lower Upper Lower Resolution Power supply voltage +7.5 V –0.5 V +6 V +2 V 1 mV ±(0.2% of reading + 1 mV) monitor +7.5 V –0.5 V +4 V +2 V +7.5 V...
  • Page 175 5.25 AQ2200-642 Transceiver I/F Module C Bus Signal Specifications Item Specifications Signal rate 100/400 kHz DC response VOLmax 0.5 V VOHmin — (Open Drain) IOLmax +3 mA IOHmax — (Open Drain) VILmax 0.7 V VIHmax 1.7 V VOLmax 0.5 V VOHmin —...

  • Page 176: Aq2200-651 Sg Module

    5.26 AQ2200-651 SG Module Performance and Functional Specifications Item Specifications RF OUT (CH1-CH5) Frequency range 620.0 to 720.0 MHz (when the rate is 1/1) 155.0 to 180.0 MHz (when the rate is 1/4) Frequency resolution 1 Hz Frequency accuracy ±2.0 ppm (when using the internal oscillator) Depends on the signal received by 10 MHz REF IN (when using an external reference signal) Output Amplitude...

  • Page 177: External Dimensions

    5.27 External Dimensions Unit: mm Unless otherwise specified, tolerances are ±3% (however, tolerances are ±0.3 mm when below 10 mm). AQ2211 Frame Controller Rear view 14.3 25.4 5-40 IM 735101-01EN...
  • Page 178 5.27 External Dimensions AQ2212 Frame Controller Rear view Index 14.3 14.3 25.4 5-41 IM 735101-01EN...
  • Page 179 5.27 External Dimensions AQ2200-231/241 Optical Sensor Head DEPTH 5 ± 3 ± 3 44.6 ± 3 AQ2200-232/242 Optical Sensor Head 4-M4 DEPTH 5 DEPTH 7 ± 3 ± 1 ± 3 ± 3 5-42 IM 735101-01EN...
  • Page 180 5.27 External Dimensions AQ2200 Series 1-Slot Size Module YOKOGAWA 321.5 Index AQ2200 Series 2-Slot Size Module YOKOGAWA 62.5 321.5 5-43 IM 735101-01EN...
  • Page 181 5.27 External Dimensions AQ2200 Series 3-Slot Size Module YOKOGAWA 321.5 5-44 IM 735101-01EN...

  • Page 182: Index

    Index Numerics Page Page 10 Gbit/s BERT module ............1-21 HOLD..................1-3 10 Gbit/s optical modulator (wavelength: 1.31 μm) .... 1-22 10 Gbit/s optical modulator (wavelength: 1.55 μm) .... 1-22 Page 10 Gbit/s optical receiver ............ 1-23 instrument information, displaying ........4-26 100 V ..................
  • Page 183 Index SLOT ..................1-3 SUMMARY ................1-3 SUMMARY screen ............... 1-4 SYSTEM ................1-3 Page TLS module ................1-9 Transceiver I/F Module ............1-25 TRIGGER IN ................. 3-1 TRIGGER OUT .............. 3-2, 3-7 Page USB memory device ............4-19 Page version information, displaying ...........

This manual is also suitable for:

Aq2211Aq2212

Table of Contents
