HANDLING INSTRUCTION
opticalCON
A. HANDLING INSTRUCTION
3
|
NO2-4FDW-A Soldering Instruction
Cable Preparation
A
Strip all 4 copper cords at a length of
3 mm, while using the baring tool.
Slide the prepared shrink tube with a length
B
of 10 mm over copper cord (pin 1 and 4).
C
Pre-solder tip of the copper cords for
enhanced heat transfer.
ATTENTION! Don't use too much solder.
Page 1
