Overview

•
Overview
The Cisco Nexus 9364C-GX switch (N9K-C9364C-GX) is a 2-rack unit (RU), fixed-port switch designed
for spine-leaf-APIC deployment in data centers. This switch has the following ports:
• 64 100-Gigabit SFP28 ports
• Two management ports (one RJ-45 port and one SFP port)
• One console port
• 1 USB port
Note
For ports 1 through 64, every 4 ports (1-4, 5-8, 9-12, and so on, referred to as a "quad") operates at a fixed
speed. That is, all 4 ports will operate in 10G, or 40G or 100G. This switch does not support mixed speeds in
quad form.
This switch includes the following user-replaceable components:
• Fan modules (three) with the following airflow choices:
• Power supply modules (two—One for operations and one for redundancy [1+1]) with the following
Overview, on page 1
• Port-side exhaust fan module with blue coloring (NXA-FAN-160CFM2-PE)
• Port-side intake fan module with burgundy coloring (NXA-FAN-160CFM2-PI)
choices:
• 2000-W port-side exhaust AC power supply with blue coloring (NXA-PAC-2KW-PE)
• 2000-W port-side intake AC power supply with burgundy coloring (NXA-PAC-2KW-PI)
• 2000-W port-side intake HVAC/HVDC power supply with burgundy coloring (NXA-PHV-2KW-PI)
• 2000-W port-side exhaust DC power supply with blue coloring (NXA-PDC-2KW-PE)
• 2000-W port-side intake DC power supply with burgundy coloring (NXA-PDC-2KW-PI)
