Attaching Front-Mount Brackets to the Chassis

2
Step 5 Repeat Steps 2 and 3 to attach the other expanding bottom-support rails to the other side of the rack.
Check the two installed bottom support rails to be sure that both have their chassis stops by the same aisle
Note
(either both by the hot aisle or both by the cold aisle) and that both rails are level and level with each other. If
they are not level, adjust the higher rail down to the level of the lower rail.
What to do next
You are ready to install two front-mount brackets on the chassis.
Attaching Front-Mount Brackets to the Chassis
You need to attach a right-angled bracket to each side of the chassis. This bracket holds the chassis in place
on a four-post rack.
Before you begin
• You must have the following tools and equipment:
Step 1
Align the two holes in one side of one of two front-mount brackets to two holes on the left or right side of the chassis
(see the following figure).
Be sure that the other side of the bracket is facing toward the front (port end) of the chassis.
1 Front-mount bracket with two screw holes aligned to
two screw holes in the chassis and one screw hole
facing the front (port side) of the chassis.
Step 2 Use two M4 x 6 mm screws to attach the bracket to the chassis. Tighten each screw to 11 to 15 in-lb (1.2 to 1.7 N·m).
Step 3 Repeat Steps 1 and 2 to attach the second center-mount bracket to the other side of the chassis.
What to do next
You are ready to mount the chassis to the four-post rack.
Cisco Nexus 9364C-GX ACI-Mode Switch Hardware Installation Guide
16
Chassis stop on the
expanding bottom-support
bracket
• Manual Phillips-head torque screwdriver
• Front-mount brackets (2) and screws (4) (found inside the switch accessory kit)
2 Two M4 x 6 mm screws used to fasten the bracket to
the chassis.
Installing the Chassis
