Switch and Module Weights and Quantities

Switch and Module Weights and Quantities

Component
Cisco Nexus 9364C-GX Chassis
(N9K-C9364C-GX)
Fan Module
– Port-side exhaust (blue)
(NXA-FAN-160CFM-PE)
– Port-side intake (burgundy)
(NXA-FAN-160CFM-PI)
Power Supply module
– 2000-W AC port-side exhaust
(blue) (NXA-PAC-2KW-PE)
– 2000-W AC port-side intake
(burgundy) (NXA-PAC-2KW-PI)
– 2000-W HVAC/HVDC port-side
intake (burgundy)
(NXA-PHV-2KW-PI)
– 2000-W DC port-side exhaust
(blue) (NXA-PDC-2KW-PE)
– 2000-W DC port-side intake
(burgundy) (NXA-PDC-2KW-PI)

Transceiver and Cable Specifications

To determine which transceivers, adapters, and cables are supported by this switch, see
c/en/us/support/interfaces-modules/transceiver-modules/products-device-support-tables-list.html.
To see the transceiver specifications and installation information, see
interfaces-modules/transceiver-modules/products-device-support-tables-list.html.

Switch Power Input Requirements

The following table lists the typical amount of power that the switch consumes. It also lists the maximum
amount of power that you must provision for the switch and power supply for peak conditions.
Note Some power supplies have capabilities that are greater than the maximum power requirements for a switch.
To determine the power consumption characteristics for the switch, use the typical and maximum requirements
that are listed in the following table.
Cisco Nexus 9364C-GX ACI-Mode Switch Hardware Installation Guide
44
Weight per Unit
27.4 lb (12.4 kg)
—
1.3 lb (0.59 kg)
1.3 lb (0.59 kg)
—
2.64 lb (1.2 kg)
2.64 lb (1.2 kg)
2.42 lb (1.1 kg)
2.42 lb (1.1 kg)
2.42 lb (1.1 kg)
System Specifications
Quantity
1
3
2 (1 for operations and 1 for
redundancy)
