- Page 1 STEP X - Name of Step QUICK START GUIDE IC402A-R2 USB 2.0 EXTENDER 24/7 TECHNICAL SUPPORT AT 877.877.2269 OR VISIT BLACKBOX.COM...
- Page 2 STEP 1 - Connect Local to Remote via CAT5e/6/7 cable CAT5E/6/7 CABLE (NOT INCLUDED) MAXIMUM LENGTH: REMOTE EXTENDER, LOCAL EXTENDER, 330 FEET (100 M) FRONT VIEW FRONT VIEW CONNECT LOCAL TO REMOTE Place the units where desired, and connect the CAT5e/6/7 (solid core) extension link cabling into the Link ports (RJ-45) of the Local and Remote Extenders.
- Page 3 STEP 2 - Connect the power adapter PLUG THE POWER ADAPTER INTO EITHER THE LOCAL OR REMOTE UNIT CAT5E/6/7 CABLE (NOT INCLUDED) MAXIMUM LENGTH: REMOTE EXTENDER, LOCAL EXTENDER, 330 FEET (100 M) FRONT VIEW FRONT VIEW Connect the power adapter into your desired unit—Local Extender or Remote Extender.
- Page 4 STEP 3 - Connect the Local Extender to your computer LOCAL EXTENDER, BACK VIEW COMPUTER USB T YPE B CONNECTOR USB T YPE A CONNECTOR USB CABLE Connect the Local Extender into your computer using the included USB 2.0 cable.
- Page 5 1. Go to www.blackbox.com 2. Enter the part number (IC402A-R2) in the search box. 3. Click on the product in the “Product Results” page. 4. Click on the “Support” tab on the product page,...
- Page 6 STEP X - Name of Step COPYRIGHT 2017 BLACK BOX CORPORATION. ALL RIGHTS RESERVED.
