Black Box IC408A Quick Start Manual

4-Port USB Extender over LAN Quick Start Guide
Extend all USB 2.0 devices to hosts across a Gigabit Ethernet Local Area Network (LAN)
using existing cabling.
1
Place the Local Extender where desired and connect the
CAT5e patch cable from the Link port (RJ-45) to a network
switch or wall network port connected to a switch.
Maximum 330 ft. (100 m)
between network devices
3
Place the Remote Extender where desired. Connect the
1
CAT5e patch cable from the Link port (RJ-45) to a network
switch or wall network port connected to a switch and
connect the Remote Extender to a power source.
Maximum 330 ft. (100 m)
between network devices
Customer
Support
Information

Network Connect

Order toll-free in the U.S.: Call 877-877-BBOX (outside U.S. call 724-746-5500)
FREE technical support 24 hours a day, 7 days a week: Call 724-746-5500 or fax 724-746-0746
Mailing address: Black Box Corporation, 1000 Park Drive, Lawrence, PA 15055-1018
Web site: www.blackbox.com • E-mail: info@blackbox.com
BLACK BOX
2
Connect the Local Extender to the computer using the
included USB cable.
Computer
4
Attach the USB device(s) to the Remote Extender.
February 2010 IC408A
MT1000A-85-R4
®
