User Manual
1-Port USB 2.0 CAT5 Extender Quick Start Guide
Break the USB distance barrier! Place USB devices
up to 328 feet (100 meters) from the computer.
Extends beyond the standard 16-foot (5-m) cable limit
for USB peripheral devices.
Installation Steps
Before you get started, make sure that all drivers required by your USB device are installed.
1. Place units where desired and connect the CAT5e/6/7 extension link cabling to the Link ports (RJ-45) on the local and remote
extender units.
Contact
Information
IC401A-R2 Local
Extender Unit
Figure 1. Step 1.
Order toll-free in the U.S. or for FREE 24/7 technical support: Call 877-877-BBOX
(outside U.S. call 724-746-5500)
www.blackbox.com • info@blackbox.com
IC401A-R2 Remote
Extender Unit
CAT5e/6/7 cable (not included),
maximum length 328 feet (100 m)
To continue with installation, turn this page over...
February 2010
IC401A-R2
MT1000A-85-R4
Advertisement
Table of Contents
Related Manuals for Black Box IC401A-R2
Summary of Contents for Black Box IC401A-R2
- Page 1 Before you get started, make sure that all drivers required by your USB device are installed. 1. Place units where desired and connect the CAT5e/6/7 extension link cabling to the Link ports (RJ-45) on the local and remote extender units. IC401A-R2 Local IC401A-R2 Remote Extender Unit...
- Page 2 (1) this device may not cause harmful interference, and (2) this device must accept any interference received including interference that may cause undesired operation. CE Statement: Black Box declares under our sole responsibility that this product, to which this declaration relates, is in conformity with European Standard EN 55022, EN 61000 and EN 55024.
