- Page 1 STEP X - Name of Step QUICK START GUIDE IC404A-R2, IC406A-R2 4-PORT EXTENDER 24/7 TECHNICAL SUPPORT AT 877.877.2269 OR VISIT BLACKBOX.COM...
- Page 2 REMOTE EXTENDER, LOCAL EXTENDER, REAR VIEW REAR VIEW FOR IC404A-R2: MULTIMODE FIBER CABLE (NOT INCLUDED), MAXIMUM LENGTH: 1600 FEET (500 M) FOR IC406A-R2: SINGLE-MODE FIBER CABLE (NOT INCLUDED), MAXIMUM LENGTH: 6.2 MI. (10 KM) BEFORE YOU GET STARTED CHOOSING FIBER CABLE...
- Page 3 STEP 2 - Connect the Local Extender to your computer USB CABLE LOCAL EXTENDER, REAR VIEW COMPUTER CONNECT LOCAL TO COMPUTER Connect the Local Extender into your computer using the included USB 2.0 cable.
- Page 4 1. Go to www.blackbox.com 2. Enter the part number (IC404A-R2 or IC406A-R2) in the search box. 3. Click on the product in the “Product Results”...
- Page 5 STEP 4 - Attach the USB device(s) to Remote Extender REMOTE EXTENDER, FRONT VIEW USB CABLE USB CABLE ATTACH USB DEVICE(S) Attach the USB device(s) to the Remote Extender. NOTE: These USB cables are NOT included.
- Page 6 STEP X - Name of Step COPYRIGHT 2017 BLACK BOX CORPORATION. ALL RIGHTS RESERVED.
