-R2
1-Port CAT5e/6/7 USB 2.0 Extender User Manual
Break the USB distance barrier! Now you can
place USB devices up to 330 feet (100 meters)
from the computer.
Extends beyond the standard 1.5-foot (5-m) cable limit for USB peripheral
devices.
Contact
Information
Order toll-free in the U.S. or for FREE 24/7 technical suppport: Call 877-877-BBOX
(outside U.S. call 724-746-5500)
www.blackbox.com • nfo@blackbox.com
IC401A-R2

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the IC401A-R2 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Black Box IC401A-R2

Summary of Contents for Black Box IC401A-R2

  • Page 1 IC401A-R2 1-Port CAT5e/6/7 USB 2.0 Extender User Manual Break the USB distance barrier! Now you can place USB devices up to 330 feet (100 meters) from the computer. Extends beyond the standard 1.5-foot (5-m) cable limit for USB peripheral devices.
  • Page 2 Canada. Le présent appareil numérique n’émet pas de bruits radioélectriques dépassant les limites applicables aux appareils numériques de classe B prescrites dans le Règlement sur le brouillage radioélectrique publié par Industrie Canada. Page 2 IC401A-R2 User Manual 877-877-2269 | blackbox.com...
  • Page 3 11. El aparato eléctrico deberá ser connectado a una fuente de poder sólo del tipo descrito en el instructivo de operación, o como se indique en el aparato. IC401A-R2 User Manual Page 3 877-877-2269 | blackbox.com...
  • Page 4 C: El aparato ha sido expuesto a la lluvia; o D: El aparato parece no operar normalmente o muestra un cambio en su desempeño; o E: El aparato ha sido tirado o su cubierta ha sido dañada. Page 4 IC401A-R2 User Manual 877-877-2269 | blackbox.com...

  • Page 5: Trademarks Used In This Manual

    Trademarks Used in this Manual Trademarks Used in this Manual Black Box and the Double Diamond logo are registered trademarks of BB Technologies, Inc. Mac is a registered trademark of Apple Computer, Inc. Linux is a registered trademark of Linus Torvalds.

  • Page 6: Table Of Contents

    Option 1: USB Extender Mounting Kit ............18 Option 2: USB Extender Direct Surface Mounting ........19 5. Troubleshooting ..................21 5.1 Troubleshooting Tips .................21 5.2 Contacting Black Box................23 5.3 Shipping and Packaging ..............23 Appendix. Technical Glossary .................24 Page 6 IC401A-R2 User Manual...

  • Page 7: Specifications

    Available Current: Up to 1 A per USB port Size — Local Extender Unit: 3.4"H x 3"W x 1"D (8.6 x 7.6 x 2.6 cm); Remote Extender Unit: 3.4"H x 3"W x 1"D (8.6 x 7.6 x 2.6 cm) IC401A-R2 User Manual Page 7 877-877-2269 | blackbox.com...

  • Page 8: Overview

    • Provides (1) remote USB 2.0 port. Number of devices can be increased using additional USB hubs. • AC power adapter at remote extender unit supplies standard 1 A to USB port. • Power adapter at local extender unit is not required for normal operation. Page 8 IC401A-R2 User Manual 877-877-2269 | blackbox.com...

  • Page 9: What's Included

    Black Box Web site. Go to www.blackbox.com, enter the part number (IC401A-R2) in the search box, click on the product in the “Product Results” page, then click on the “Support” tab on the product page, and select the document you wish to download.

  • Page 10: Hardware Description

    USB on the host computer. Figures 2-1 and 2-2 show the front and back panels of the LEX. Table 2-1 describes their components. Figure 2-1. Front view: local unit. Figure 2-2. Back view: local unit. Page 10 IC401A-R2 User Manual 877-877-2269 | blackbox.com...
  • Page 11 When the LEX and REX are in suspend mode, the LED is off. USB Type B connector Connects the LEX unit to the host computer. Link Port (RJ-45) Accepts an RJ-45 connector for CAT5e/6/7 cabling to the REX unit. IC401A-R2 User Manual Page 11 877-877-2269 | blackbox.com...

  • Page 12: Remote Extender (Rex) Unit

    AC adapter and can supply up to 1 A to each USB port. Figures 2-3 and 2-4 show the front and back panels of the REX. Table 2-2 describes their components. Figure 2-3. Front view: remote unit. Figure 2-4. Back view: remote unit. Page 12 IC401A-R2 User Manual 877-877-2269 | blackbox.com...
  • Page 13 Accepts RJ-45 connector for CAT5e/6/7 cabling to connect the local Link Port (RJ-45) extender to the remote extender unit. Connects to the AC power supply. Required at REX for proper Power Port operation. IC401A-R2 User Manual Page 13 877-877-2269 | blackbox.com...

  • Page 14: Typical Installation

    Remote CAT6/7 cable Local Extender Extender Unit (REX) Unit (LEX) Host computer USB 2.0 and 1.1 devices Figure 2-5. USB extension up to 328 feet (100 m) using CAT5e (or better) cable. Page 14 IC401A-R2 User Manual 877-877-2269 | blackbox.com...

  • Page 15: Installation

    2. Connect the patch cable into the Link port of the local extender. 3. Connect a CAT 5e/6/7 patch cable (not provided) into the information outlet near the USB devices. IC401A-R2 User Manual Page 15 877-877-2269 | blackbox.com...

  • Page 16: Installing The Remote Extender (Rex) Unit

    NOTE: To open System Profiler in OS X: Open the Finder, select Applications, then open the Utilities folder and double click on the System Profiler icon. 4. If the extender is not detected correctly or fails to detect, consult Section 5, Troubleshooting. Page 16 IC401A-R2 User Manual 877-877-2269 | blackbox.com...

  • Page 17: Connecting A Usb Device

    USB device(s), as required. 2. Connect the USB device to the device port on the REX unit. 3. Check that the device is detected and installed properly in the operating system. IC401A-R2 User Manual Page 17 877-877-2269 | blackbox.com...

  • Page 18: Usb Extender Mounting Options

    Chapter 4: USB Extender Mounting Options 4. USB Extender Mounting Options The bottom of the IC401A-R2 enclosures feature four convenient pre-drilled holes for optional direct surface mounting and four mounting slots for easy cable-ties. Based on your requirements, choose from three available mounting options: 1.

  • Page 19: Option 2: Usb Extender Direct Surface Mounting

    Option 2: USB Extender Direct Surface Mounting (using your own hardware) The bottom of the IC401A-R2 enclosures feature four pre-drilled holes for optional direct surface mounting. Using the stencil below, along with your own hardware you can directly mount your USB Extender on a surface.
  • Page 20 Figure 4-3. Mounting measurement stencil. Option 3: Cable-Tie Mounting The bottom of the IC401A-R2 enclosure also features four convenient slots for cable mounting. Simply thread a cable tie, (also called tie-wrap or zip tie), into the mounting slot and through the cable tie head, and secure it to a pole or other surface by pulling it tight.

  • Page 21: Troubleshooting

    Table 5-1 provides troubleshooting tips. The topics are arranged in the order in which they should be executed in most situations. If you are unable to resolve the problem after following these instructions, contact Black Box Technical Support at 877-877-2269 or info@blackbox.com.
  • Page 22 1. Use a different LEX/REX pair that has the same firmware Host and Link LEDs revision. Firmware mismatch on the LEX/REX between the LEX and the 2. Upgrade the LEX/REX firmware. Contact Black Box units blink REX. Technical Support at 724-746-5500 or intermittently. info@blackbox.com for assistance.

  • Page 23: Contacting Black Box

    • Package it carefully. We recommend that you use the original container. • If you are returning the unit, make sure you include everything you received with it. Before you ship for return or repair, contact Black Box to get a Return Authorization (RA) number.

  • Page 24: Appendix. Technical Glossary

    (Table 6-1) or the T568B scheme (Table 6-2) for cable termination. The 1-Port CAT5e USB 2.0 Extender uses all four pairs of the cable. RJ-45 connectors are sometimes also referred to as 8P8C connectors. Page 24 IC401A-R2 User Manual 877-877-2269 | blackbox.com...
  • Page 25 Figure A-2. RJ-45 connector White/Brown using T568A wiring. Brown Table A-2. T568B wiring. Pair Wire Cable Color White/Orange Orange White/Green Blue White/Blue Green White/Brown Figure A-3. RJ-45 connector using T568B wiring. Brown IC401A-R2 User Manual Page 25 877-877-2269 | blackbox.com...
  • Page 26 NOTES Page 26 IC401A-R2 User Manual 877-877-2269 | blackbox.com...
  • Page 27 NOTES IC401A-R2 User Manual Page 27 877-877-2269 | blackbox.com...
  • Page 28 877-877-2269 or blackbox.com. About Black Box Black Box provides an extensive range of networking and infrastructure products. You’ll find everything from cabinets and racks and power and surge protection products to media converters and Ethernet switches all supported by free, live 24/7 Tech support available in 60 seconds or less.
