- Page 1 PRL POWER AMPLIFIERS PRL500 PRL900 PRL1300...
- Page 2 • Connect the Power Load Bank with Speakon on the output sockets. • Connect the Dual-channel Oscilloscope on Binding Post outputs. • Connect the PROEL Test Cable to the TP Test Points of the amplifier and the two other side terminals to the Testers setted at 200mV range.
- Page 3 PRL500 - 900 - 1300 B i a s C a l i b r a t i o n Required Test Equipment: • Function Generator • 20 Mhz Dual-channel Oscilloscope • Power Load Bank (4Ω - 350W min.) • Variac (0V ac – 230V ac, 15A) Test Procedure Connections: •...
- Page 4 100N 47U 25V IC2-A IC2-B 100N 100N 100N 100N TL072 9K09 1% 18K 1% TL072 9K09 1% 18K 1% -15VB Title CROSSOVER PRL 1300/900/500 100N Size Number Revision 47U 25V Date: 23-May-2001 Sheet of File: A:\PRL1300-900-500.ddb Drawn By: PROEL S.p.A.
- Page 5 LEFT 330R 330R CLIP CLIP LM324 LM324 100K 220K 220K +12V +12V IC1-B IC1-C SIGNAL SIGNAL 100N LM324 LM324 100K PROT RIGHT Title LED CONTROL PRL 1300/900/500 Size Number Revision Date: 23-May-2001 Sheet of File: A:\PRL1300-900-500.ddb Drawn By: PROEL S.p.A.
- Page 6 100U OUT_R GND_R +12V MC7812 5E6 2W +12V 100uH 10E 2W 10E 2W -12V 2200U W02M 100N 100V 2200U Title POWER SUPPLY PRL 500 -12V Size Number Revision MC7912 -12V Date: 23-May-2001 Sheet of File: A:\PRL1300-900-500.ddb Drawn By: PROEL S.p.A.
- Page 7 100U OUT_R GND_R +12V MC7812 5E6 2W +12V 100uH 10E 2W 10E 2W -12V 2200U W02M 100N 100V 2200U Title POWER SUPPLY PRL 900 -12V Size Number Revision MC7912 -12V Date: 23-May-2001 Sheet of File: A:\PRL1300-900-500.ddb Drawn By: PROEL S.p.A.
- Page 8 100U OUT_R GND_R +12V MC7812 5E6 2W +12V 100uH 10E 2W 10E 2W -12V 2200U W02M 100N 100V 2200U Title POWER SUPPLY PRL 1300 -12V Size Number Revision MC7912 -12V Date: 23-May-2001 Sheet of File: A:\PRL1300-900-500.ddb Drawn By: PROEL S.p.A.
- Page 9 TR16 MJ21194 MJ21194 MJ21194 MJ21194 22E 1W 4V7 1W 220U 25V 120N 15V 1W -15VB 1K2 5W 47U 25V 1N4007 BRIDGE Title STEREO POWER AMP. PRL 500 Size Number Revision Date: 23-May-2001 Sheet of File: A:\PRL1300-900-500.ddb Drawn By: PROEL S.p.A.
- Page 10 MJ21194 MJ21194 MJ21194 MJ21194 MJ21194 22E 1W 4V7 1W 220U 25V 120N 15V 1W -15VB 1K5 7W 47U 25V 1N4007 BRIDGE Title STEREO POWER AMP. PRL 900 Size Number Revision Date: 23-May-2001 Sheet of File: A:\PRL1300-900-500.ddb Drawn By: PROEL S.p.A.
- Page 11 MJ21194 MJ21194 MJ21194 MJ21194 MJ21194 22E 1W 4V7 1W 220U 25V 120N 15V 1W -15VB 2K2 7W 47U 25V 1N4007 BRIDGE Title STEREO POWER AMP. PRL 1300 Size Number Revision Date: 23-May-2001 Sheet of File: A:\PRL1300-900-500.ddb Drawn By: PROEL S.p.A.
