COMMAND
CHG-ACCMD-T1
CHG-LPBK-T1
CHG-TSTSIG-T1
CONN-TACC-T1
DISC-MEAS
DISC-TACC
DISC-TSTSIG
MEAS-SIG-T1
REPT-RSLT
TST-INSERRBITS

7 SPECIFICATIONS

The technical specifications for the RTAU modules are given in Table 5.
PARAMETER
Input Power
Input Current (Max.)
Input Current (Nominal)
Input Voltage (Nominal)
Input Voltage Range
Power Consumption /
Dissipation (Max.)
DS1 Jack Access
Electrical Interface
Termination
Jack Type
Line Code
Line Rate
Dimensions
Height × Width × Depth
Weight
Environment
Operating Temperature
Storage Temperature
Relative Humidity (Operating)
Altitude (Operating
or Non-operating)
Table 4. TL1 Commands Used for the RTAU
DESCRIPTION
Change Access Mode T1
Change Loopback T1
Change Test Signal T1
Connect Test Access T1
Disconnect Measurement
Disconnect Test Access Metallic/Digital
Disconnect Test Signal
Measure Signal T1
Report Result
Test Insert Error Bits
Table 5. RTAU Specifications
SPECIFICATION
175 mA at 48 Volts
–
100 mA at 48 Volts
–
–48 Vdc
–42 to –60 Vdc
8.2 watts
Bipolar
100 ohms nominal ± 5%
Bantam
AMI or B8ZS
1.544 Mbps ± 130 ppm max.
9.5 × 9.9 × 1.0 inches
(24.1 × 25.1 × 2.5 cm)
12 oz. (.34 kg)
–40° to 149° F (–40° to 65° C)
–40° to 158° F (–40° to 70° C)
5% to 95%
–1,312 to + 14,764 ft.
400 to +4,500 m)
(–
ADCP-61-743 • Issue 3 • September 2004
REMARKS
Controlled by front panel switch
No condensation
