ADCP-61-743 • Issue 3 • September 2004
5. Use the arrow or number keys to select RTAU Setup and Control from the RTAU
Configuration menu. Press Enter or Return. The RTAU Setup and Control screen will
appear as shown in Figure 6.
Note: If the RTAU is not plugged into the chassis and the Test Access Unit Commands
selection is made from the System Maintenance menu, the Test Access Unit
Status/Commands screen will appear as shown in Figure 7. This screen cannot be
configured. However, if the TAU is plugged into the chassis and the Test Access Unit
Commands selection is made from the System Maintenance menu, the Test Access Unit
Status/Commands screen will appear and can be configured.
