8. SPECIFICATIONS
Input AC
Voltage
Inrush Current
THD
Power Factor
Output DC
Voltage
Current Limit
Power Limit
Efficiency
Regulation
Noise
Protection
Short Circuit
Reverse Battery Polarity
High Voltage Shutdown
Electrostatic Discharge (ESD)
AC Surge
RF Immunity
RF Emissions
Environmental
Operating
Full Power
Derated Operation
Storage/Transport
Humidity
Acoustic Noise
Mechanical Dimensions
Width
Depth
Height*
Agency Compliances
Safety
EMC
Environmental
PM990-4207-00, Rev 6
Universal AC 85-300VAC (L-N. 1ph, or 3ph-Y, 3ph-delta [option].
Fully protected up to 440VAC (L-N)
<9A RMS per rectifier
Line Harmonics meet EN61000-3-2
>0.98 for >50% output power
-48VDC systems, adjustable range 42.0V to 59.5V
+24VDC systems, adjustable range 21.0V to 30.0V
Adjustable from 20 % to 120 % of rated output current
Varies by rectifier model. See the rectifier brochures for more information.
>90% at 100% output power for 48VDC systems
>88% at 100% output power for 24V systems
+/- 1% or better over line, load and temperature
<1mV RMS Psophometrically weighted
<32dBrnC Voiceband
<10mV RMS and <100mV peak-to-peak (10kHz-100MHz)
Can sustain short circuit at output terminals indefinitely
Internal fuse at output of RECTIFIER, integral battery circuit breakers and
detection/disconnection circuitry
Rectifier shuts down if output exceeds programmed overvoltage limit
IEC 61000-4-2 (Level 4: Air 15kV, Contact 8kV)
IEC 61000-4-4 (EFT), Level 4
IEC 61000-4-5 (Impulse), Level X: 6kV/3kA
IEC 61000-4-12 (Ringwave), Level X: 6kV/500A
IEC 61000-4-3 (Radiated), Level 4
IEC 61000-4-6 (Conducted), Level 3
CISPR 22 Class B, (Conducted & Radiated)
-40°C to +70°C
-40°C to +55°C
50% power at +70°C
-40°C to +70°C
0 to 100% relative humidity, condensing
< 60dB (A weighting)
483mm (19")
355mm (14")
88mm – 352mm (3.4" – 13.6") *depending on configuration
IEC 60950, UL/CSA 60950
ETSI EN 300 386 V1.3.2 (2002-12)
ETSI EN 300 019
