- Page 1 Sageon™ Site Monitor (SSM) Application Note UNIPOWER, LLC 3900 Coral Ridge Drive Coral Springs, FL 33065 Phone: +1- 954-346-2442 Toll Free: 1-800-440-3504 AN103-4012-00, Issue 3 Web site – http://www.unipowerco.com...
- Page 2 Until the equipment is securely mounted, be careful to prevent the equipment from being accidentally tipped over. NAMEPLATE Each piece of UNIPOWER equipment is identified by a part number on the nameplate. Please refer to this number in all correspondence with UNIPOWER. INITIAL SETTINGS All equipment is shipped from our production area fully checked and adjusted.
- Page 3 PROPRIETARY AND CONFIDENTIAL The information contained in this product manual is the sole property of UNIPOWER, LLC. Reproduction of the manual or any portion of the manual without the written permission of UNIPOWER, LLC is prohibited. © Copyright UNIPOWER, LLC 2015...
- Page 4 Sageon Site Monitor (SSM) Application Note INTRODUCTION The Sageon Site Monitor (SSM) is an auxiliary module for the Sageon DC Power Plant. The SSM provides additional I/O for the power plant enabling users to monitor the status of additional equipment through the Sageon system.
- Page 5 Sageon Site Monitor (SSM) Application Note SYSTEM CONFIGURATION The SSM is easily configured using the SageView program included with each Sageon DC Power Plant. The Site Monitor configuration screen is pictured below and provides a simple, intuitive user interface. Each input has a user-defined label field (up to 8 characters) to describe its function. If a label field is left blank, the corresponding input is treated as not used.
- Page 6 Sageon Site Monitor (SSM) Application Note PHYSICAL SPECIFICATION Module Dimensions (approx): 5.11” x 9.37” x 3.14” (130 x 238 x 80) (DxWxH) AN103-4012-00, Issue 3...
