Installation Manual
Half-dome Facial Capture Camera Series
Version: 1.0.2
Date: 12/29/2018
Applicable model: FC700, FI700

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FC700 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for ZKTeco FC700

  • Page 1 Installation Manual Half-dome Facial Capture Camera Series Version: 1.0.2 Date: 12/29/2018 Applicable model: FC700, FI700...
  • Page 2 All rights including intellectual or industrial property rights in any information, content, pictures, graphics, materials, data or processes disclosed or discussed in this manual shall belong to ZKTeco co., LTD and its subsidiaries (hereinafter the "company" or "ZKTeco"). No group or individual may take excerpts of, copy, translate or edit all or part of this manual by any means without written permission from the company.
  • Page 3 Photographs, graphics, diagrams, and illustrations provided in the manual are for reference only. Release history Date Version Change 09/27/2018 New release version Contacts Email: sales@zkteco.com For additional offices around the world, see www.zkteco.com corporate offices. Half-dome Facial Capture Camera Series Installation Manual...
  • Page 4: Table Of Contents

    Content 1. Safety precautions ......................5 1.1 Power requirements ....................5 1.2 Use requirements ....................5 1.3 Cleaning requirements ................... 6 2. Installation Requirements ....................7 3. Preparation Tools ......................9 4. Comparison of camera view & recognition distance ............11 5.
  • Page 5: Safety Precautions

    1. Safety precautions 1.1 Power requirements  The installation and use of this product must strictly comply with local electrical safety standards.  The equipment supply voltage must meet the input voltage requirements of the equipment.  To prevent lightning, install lightning arrester. In order to protect the equipment safety, please effectively connect the equipment housing.
  • Page 6: Cleaning Requirements

     When installing the equipment, do not touch the camera lens, avoid scratching and stain the camera lens.  There is film-sticking equipment, please tear off the film after installation; no film-sticking equipment, after installation, please clean the equipment lens, shield, etc.
  • Page 7: Installation Requirements

     Do not use volatile solvents such as alcohol, benzene or diluents or strong, abrasive alkaline cleaners, or damage the surface coating, or reduce the performance of the equipment.  When cleaning, please use light illumination (such as mobile phone flashlight illumination) for observation.
  • Page 8  As far as possible, the camera should not be installed near objects with strong reflective characteristics such as glass, floor tiles, water surface, leaves, etc. Otherwise, it will lead to a brighter or darker picture to be monitored.  A transparent protective film is pasted on the surface of the ball cover or window of the camera.
  • Page 9: Preparation Tools

    place, give a warning in a striking location: you are in the electronic monitoring area.  The power adapter used by the device must meet the power input voltage and current requirements specified on the device label.  Check whether the network is smooth. ...
  • Page 10 Serial Tool name Specifications and uses Illustration number Cable clamp Used for making crystal heads. Wire cutting For power lines, alarm lines and so pliers Specification: H3. Inside six corner It is used to disassemble and screwdriver tighten the six angle screws in the M4 model.
  • Page 11: Comparison Of Camera View & Recognition Distance

    4. Comparison of camera view & recognition distance Installation height: 2-2.5 meters, recommended installation height of 2.3 meters.  Recognition width: 2.5-3.5 M  Focal Recognition Installation diagram length distance 6.0mm 2-4m 8.0mm 3-5m 12mm 4-8m 16mm 6-11m 25mm 10-18m 35mm 16-28m 60mm...
  • Page 12  Step 3: arrange and connect the power cable, net cable and other cables of the camera, and do a good job of power line insulation and water treatment.  Step 4: Align the base position of the camera with the mounting plateposition, and rotate the fuselage so that the camera is fixed to the mounting plate, as shown in the figure.
  • Page 13: Bracket Installation

    5.2 Bracket installation  Step 1: Install the bracket: The bracket selected needs to be screwed, the bracket transfer bowl is installed on the main body of the bracket, and then the main body of the bracket is screwed on the installation wall. ...
  • Page 14: Network Connection

     Step 6: Complete the installation: tighten the screws on the camera cover assembly, and tighten the anti-removal screws, complete the installation of the camera, as shown in the figure. 6. Network Connection 6.1 Connect directly through the network cable Half-dome Facial Capture Camera Series Installation Manual...
  • Page 15: Connected Through Switches Or Routers

    6.2 Connected through switches or routers. 7. login webcam 7.1 Install plug-in 7.1.1 Preparation before plug-in installation  The camera is connected to a 12V power supply after it is connected to the LAN through a network line. The device management software is used to search the IP address of the camera after one minute of power-on.
  • Page 16: Ping Camera

    7.1.2 ping Camera  Search the IP address to enter the browser's address bar and press enter to start loading controls. If you can search the camera IP but cannot login, you can confirm the reason through the following methods: ...
  • Page 17 2) Click "Allow" in the figure above and the following icon annotation will appear: 3) Click Installation to pop up the dialog box as shown in the following figure:  If the plug-in fails to install, the IE security level needs to be modified. The modification steps are as follows: ...
  • Page 18: Web Login Camera

     Enable the right to download and install Activex controls and plug-ins, as shown in the following figure. After confirming the application, refresh IE browser and start downloading and installing IE controls. 8. WEB Login camera 8.1 First WEB login camera ...
  • Page 19 device through the IE browser. After the computer IP settings are completed, open the IE browser, enter the IP address of the device in the address bar, press the Enter key, and the WEB login interface will be displayed. The initial IP address of the camera is 192.168.1.2.
  • Page 20: Non First Web Login Camera

    Step 5. After installing the plug-in, enter the login password, login the device and enter the WEB  main interface as shown in the figure 8.2 Non first WEB login camera  Step 1: Open the IE browser, enter the IP address of the device in the address bar, press the Enter key, and the WEB login interface will be displayed.
  • Page 21 Half-dome Facial Capture Camera Series Installation Manual...
  • Page 22 Half-dome Facial Capture Camera Series Installation Manual © Copyright 2018. ZKTeco Inc. ZKTeco Logo is a registered trademark of ZKTeco or a related company. All other product and company names mentioned are used for identification purposes only and may be the trademarks of their respective owners. All specifications are subject to...
