FITS: 2016+ Hyundai Tucson
QTY PART DESCRIPTION
1
Rear Guard
1
LEFT Mounting Bracket
1
RIGHT Mounting Bracket
4
M12X30 HEX HEAD BOLTS
8
M12 FLAT WASHERS
LEFT Mounting Bracket
REMOVE CONTENTS FROM BOX. VERIFY ALL PARTS ARE PRESENT
READ INSTRUCTIONS CAREFULLY BEFORE STARTING INSTALLATION
Install Time: 30 – 60 Minutes; Professional Installation
INSTALLATION PROCEDURE
1. Pls prepare the tools for installation,follow as: 12-14、17-19 wrench.
2. Put the mount bracket into the girder of the car,and tighten it with M10-1.25*30 Hex bolt.
3. Install the Rear Guard on the mount bracket ,and tighten it with lt M12*30 Hex bolt
4. Installation is finished.
Bull Bar
Part Number: RDHY-306-55
PART LIST:
QTY PART DESCRIPTION
4
M12 LOCK WASHERS
4
M12 HEX NUT
4
M10-1.25*30 HEX HEAD BOLTS
4
M10 FLAT WASHERS
4
M10 LOCK WASHERS
Page 1 of 3
